XCS Single Axis CtrlX Converters

The XCS Single Axis CtrlX Converters series is made for accurate motor control tasks. These units have a design that puts different functional parts together. It gets a mains input rectifier, choices for braking transistors, and an inverter stage to drive the motor. Each converter includes DC bus capacitors including connection spots. You can pick setups for external braking resistors or go with built-in braking transistor/resistor combos. The model coding gives options to tweak different settings. This includes the cooling style, the highest current it can handle, how well it is protected, and the connector layout. This series works with different maximum current levels, from 10A all the way up to 375A. You can get them in air-cooled (internal) or coldplate cooling types. For protection, they have an IP20 rating and can handle AC voltage inputs from 200-500V (+10%/-15%). This makes sure they fit in with normal industrial power setups. Also, there are different power section designs for certain braking needs. You can choose standalone braking transistors or transistor/resistor combos.
