Product Description

The CLM01.3-X-0-2-0-FW is an advanced control unit produced by Rexroth Indramat to facilitate industrial production processes by providing servo systems with accurate and precise control. The control unit is highly durable and self-diagnostic, it connects to special sensors and actuators, which provides it with information about all parts of the servo system. In the case of electrical or mechanical error, the CLM01.3-X-0-2-0-FW control unit immediately alerts the operator by displaying an appropriate error message on its four-line liquid crystal display unit; the operator can thus quickly attend to the anomaly before it completely damages the control unit. The CLM01.3-X-0-2-0-FW control unit is particularly effective in machines that require simultaneous multiple axis position control; such machines include roll feeds, handling equipment, linear gantry robots, packaging machines, and lots more.

The CLM01.3-X-0-2-0-FW control unit is 390 millimetres tall and 105 millimetres wide. It weighs about 6 kilograms and has a depth of 325 millimetres. The control unit can carry out up to four-axis control while using one incremental or absolute encoder per axis. The control unit has a feed length resolution of 0.0254 millimetres; this means that the control unit accurately tracks the movement of the servo motor at very low speed.

The CLM01.3-X-0-2-0-FW control unit is produced in accordance with the IP10 protection category; this means that the housing of the control unit can only prevent the intrusion of solid materials larger than 50 millimetres in diameter. The CLM01.3-X-0-2-0-FW control unit operates optimally in ambient temperature that falls within the range of 5 to 45degree Celsius. The maximum operating height of the CLM01.3-X-0-2-0-FW control unit is about 1000 meters above sea level. Operating the CLM01.3-X-0-2-0-FW control unit outside the conditions specified in the unit's documentation can reduce the control unit's service life.
