Product Description:

The CLM01.3-X-E-2-B-FW is a position control module manufactured by Bosch Rexroth Indramat as part of the CLM Axis Positioning Control Modules series. It functions as an electronic axis controller that integrates into motion systems to execute precise closed-loop positioning on two mechanical axes and supplies coordinated command values to connected drive amplifiers in industrial automation lines. In coordinated equipment, the module acts between machine-level motion commands and the amplifier channels that drive the axes. It concentrates on trajectory control and position monitoring while the velocity loop remains in the drive.

The module comes in a standard 2-axis configuration, so each channel is prepared for incremental encoders and digital I/O used in coordinated motion. Internally, it supports interpolated positioning on 2 axes at the same time, which allows coupled movements such as electronic cams and synchronized path changes. For operator interaction, a four-line display is mounted on the front panel, where parameter numbers, current positions, and diagnostic codes can be viewed without an external terminal. Readability in dim plant areas is supported by a backlit LCD display, and background illumination helps keep the characters legible when ambient lighting changes.

The controller is delivered with expansion options, so additional memory cartridges, analog setpoint cards, or fieldbus modules can be added when application requirements increase. The unit is identified as Line 01, which keeps parameter numbering and data structures consistent with earlier units in the same family. The functional class is Indramat Position Control, indicating that the module handles trajectory generation and positional error monitoring rather than motor commutation. This separation lets the connected drives continue to manage the underlying velocity regulation for each axis.
