CLM01.3-X-E-2-0 Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911247116
The Bosch Rexroth Indramat CLM01.3-X-E-2-0 is an axis positioning control module from the CLM Axis Positioning Control Modules series. This standard 2-axis Indramat position control features a 24 Vdc control supply, standard LCD display with a four line design, and a keypad with 20 keys. It weighs 14 pounds and has dimensions of 15.35 inches in height, 4.13 inches in width, and 12.80 inches in depth.
Internal Product Review
The CLM01.3-X-E-2-0 is an Indramat position control module configured for 2-axis operation. A 24 Vdc control supply and convection cooling support dependable cabinet integration and steady thermal behavior. The four-line LCD display simplifies setup and diagnostics, making the module a strong choice for precise positioning systems.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The CLM01.3-X-E-2-0 is an axis positioning control module manufactured by Bosch Rexroth Indramat for the CLM Axis Positioning Control Modules series. Acting as an Indramat position control unit, it delivers motion setpoints to connected drives and reads encoder feedback on a built-in four-line LCD during setup and operation. The device executes interpolation, limit checking, and sequencing so automated equipment can perform repeatable linear or rotary moves with minimal PLC involvement. This operating approach suits machinery that needs coordinated positioning and local control functions in one cabinet-mounted module.
Its hardware is configured for 2-axis control and matches the standard factory profile for coordinated motion. Control electronics operate from a dedicated 24 Vdc supply that remains energized even when the main power bus is off, allowing parameter retention and safe field programming. Heat is dissipated solely by natural convection, so the controller runs silently and does not introduce airborne contaminants into sealed panels. An enclosure rating of IP10 affords basic finger protection only, so the module must be installed inside a protective cabinet. The front membrane keypad and standard LCD display give direct access to motion parameters, alarm history, and axis status without external terminals, which supports local setup and routine diagnostics.
The metal chassis is 12.80 in deep, 15.35 in high, and 4.13 in wide, enabling dense panel layouts alongside drives and contactors. At only 14 lb, the unit can be mounted on a DIN rail or directly to a backplate without extra support brackets. Thermal performance is unchanged up to the specified 3280 ft maximum operating altitude, provided vertical clearance is maintained above the top vents. Operator interaction is handled through 20 tactile keys that map to on-screen menu lines, streamlining jog, teach, and homing routines during local operation. For machines that later require more inputs, outputs, or communications, right-side expansion slots accept optional cards while retaining compatibility with the line 01 electrical backplane.
