The BTV30 Machine Control Terminals from Bosch Rexroth Indramat comprise a PC-based operator and visualization terminal series designed to integrate one or more NC controls with PLC functionality or standalone PLCs within a single machine interface platform.
The series is built around a Pentium 200 MHz slot CPU with integrated graphics and is specified with 64 MB of RAM, a hard drive of at least 1.2 GB, and a 10.4-inch TFT color display with 640 × 480 resolution. For communication and peripheral support, the terminals provide RS232 and RS232/RS485 serial interfaces, a Centronics printer port, VGA, Ethernet, and a full ASCII keyboard with eight machine function keys. The platform is expandable through nine free slots, allowing configurations with modules such as CNC controls, PLC modules, serial interface cards, PROFIBUS-DP, INTERBUS, Ethernet, and other PC104 or ISA-based options depending on the function type. For industrial installation, the series uses an IP65-rated front panel with an IP20 housing and operates on an autoranging 115/230 VAC supply.
BTV30.1CA-08R-50B-D-010200-FW
BTV30.1CA-08R-50B-D-020200-FW
BTV30.1CA-08R-50B-D-030200-FW
BTV30.1CA-16R-50B-D-010200-FW
BTV30.1CA-16R-50B-D-030200-FW
BTV30.1CA-16R-50B-D-040200-FW
BTV30.1CA-16R-50B-D-110200-FW
BTV30.1CA-16R-50B-D-120200-FW
BTV30.1CA-32R-50B-D-010200-FW
BTV30.1CA-32R-50B-D-020200-FW
BTV30.1CA-32R-50B-D-120200-FW
BTV30.1CA-32R-50B-D-140300-FW
BTV30.1CA-32R-50C-D-000100-FW
BTV30.1CA-32R-50C-D-010600-FW
BTV30.1CA-32R-50C-D-130200-FW
BTV30.1CA-32R-50C-D-140200-FW
BTV30.1CA-32R-50C-D-140300-FW
BTV30.1CA-32R-50C-D-150200-FW
BTV30.1CA-32R-50C-D-230200-FW
BTV30.1CA-64R-10D-D-120200-FW
BTV30.1CD-08R-50B-D-010200-FW
BTV30.1CD-08R-50B-D-020200-FW
BTV30.1CD-08R-50B-D-030200-FW
BTV30.1CD-16R-50B-D-010200-FW
BTV30.1CD-16R-50B-D-020200-FW
BTV30.1CD-16R-50B-D-020300-FW
BTV30.1CD-16R-50B-D-030200-FW
BTV30.1CD-16R-50B-D-030300-FW
BTV30.1CD-16R-50B-D-040200-FW
BTV30.1CD-16R-50B-D-130200-FW
BTV30.1CD-16R-50B-D-140300-FW
BTV30.1CD-32R-50B-D-010200-FW
BTV30.1CD-32R-50B-D-020200-FW
BTV30.1CD-32R-50B-D-030200-FW
BTV30.1CD-32R-50B-D-120300-FW
BTV30.1CD-32R-50B-D-130200-FW
BTV30.1CD-32R-50B-D-140200-FW
BTV30.1CD-32R-50C-D-120200-FW
BTV30.1CD-32R-50C-D-140200-FW
BTV30.1CD-32R-50C-D-220200-FW
BTV30.1CS-08R-50B-D-000100-FW
BTV30.1EA-32R-50C-D-120200-FW
BTV30.1EA-32R-50C-D-130200-FW
BTV30.1PA-08R-50B-D-000000-FW
BTV30.1PA-16R-50B-D-000000-FW
BTV30.1PA-32R-50B-D-000000-FW
BTV30.1PA-32R-50C-D-000000-FW
BTV30.1PD-16R-50B-D-000000-FW
BTV30.1PD-32R-50B-D-000000-FW
BTV30.1PD-32R-50C-D-000000-FW
BTV30.1SA-16R-50B-D-000100-FW
BTV30.1SD-32R-50C-D-000100-FW
BTV30.2CA-24R-55C-D-FW
BTV30.2CA-24R-55C-E-FW
BTV30.2CA-28B-11C-D-FW
BTV30.2CA-28R-10C-D-FW
BTV30.2CA-28R-11C-D-FW
BTV30.2CA-28R-33C-D-FW
BTV30.2CA-28R-45C-D-FW
BTV30.2CA-64B-11C-D-FW
BTV30.2CA-64R-10C-D-FW
BTV30.2CA-64R-11C-D-FW
BTV30.2CA-64R-33C-D-FW
BTV30.2EA-24R-55C-D-FW
BTV30.2EA-28B-11C-D-FW
BTV30.2EA-28R-10C-D-FW
BTV30.2EA-28R-11C-D-FW
BTV30.2EA-28R-33C-D-FW
BTV30.2EA-28R-45C-D-FW
BTV30.2EA-64B-11C-D-FW
BTV30.2EA-64R-10C-D-FW
BTV30.2EA-64R-33C-D-FW
BTV30.2PA-24R-55C-D-FW
BTV30.2PA-24R-55C-D-NW
BTV30.2PA-28B-11C-D-FW
BTV30.2PA-28R-10C-D-FW
BTV30.2PA-28R-11C-D-FW
BTV30.2PA-28R-33C-D-FW
BTV30.2PA-28R-45C-D-FW
BTV30.2PA-64B-11C-D-FW
BTV30.2PA-64B-33C-D-NW
BTV30.2PA-64R-10C-D-FW
BTV30.2PA-64R-33C-D-FW
BTV30.2SA-28B-11C-D-FW
BTV30.2SA-28R-10C-D-FW
BTV30.2SA-28R-11C-D-FW
BTV30.2SA-28R-33C-D-FW
BTV30.2SA-28R-45C-D-FW
BTV30.2SA-64B-11C-D-FW
BTV30.2SA-64R-10C-D-FW
BTV30.2SA-64R-33C-D-FW
BTV30.2TA-00R-00C-N-NW
CFG-BTV30.2C-2D-1C-NN-NN-NN-NN-NN-NN-NN
CFG-BTV30.2C-2D-2C-NN-NN-NN-NN-NN-NN-1T
CFG-BTV30.2C-B1-1S-1C-NN-NN-NN-NN-NN-NN
CFG-BTV30.2C-B1-2D-1C-NN-NN-NN-NN-NN-1T
CFG-BTV30.2C-B1-2D-1C-NN-NN-NN-NN-NN-NN
CFG-BTV30.2C-B1-2D-2C-NN-NN-NN-NN-NN-NN
CFG-BTV30.2C-B1-2D-A2-1C-NN-NN-NN-NN
CFG-BTV30.2C-B1-2D-A2-1C-NN-NN-NN-NN-NN
CFG-BTV30.2C-B1-2D-A2-2C-NN-NN-NN-NN-NN
CFG-BTV30.2C-B1-2D-A2-A2-1C-NN-NN-NN-NN
CFG-BTV30.2C-B1-2D-A2-A2-2C-NN-NN-NN-NN
CFG-BTV30.2C-B1-2D-A2-A2-A2-1C-NN-NN-NN
CFG-BTV30.2C-B1-2F-1C-NN-NN-NN-NN-NN-1T
CFG-BTV30.2C-B1-2F-1C-NN-NN-NN-NN-NN-NN
CFG-BTV30.2C-B1-2F-A2-1C-NN-NN-NN-NN-NN
CFG-BTV30.2C-B1-2F-A2-2C-NN-NN-NN-NN-NN
CFG-BTV30.2C-B1-2F-A2-A2-1C-NN-NN-NN-NN
CFG-BTV30.2C-B1-2F-A2-A2-A2-1C-NN-NN-NN
CFG-BTV30.2C-B1-2F-A2-A2-A2-2C-NN-NN-1T
CFG-BTV30.2C-BB-S4-B1-2D-1C-NN-NN-NN-NN
CFG-BTV30.2C-BB-S4-B1-2D-A2-1C-NN-NN-NN
CFG-BTV30.2C-BB-S4-B1-2F-A2-A2-1C-NN-NN
CFG-BTV30.2C-BB-S4-B1-2F-A2-A2-A2-1C-NN
CFG-BTV30.2C-BB-S4-P1-2D-1C-NN-NN-NN-NN
CFG-BTV30.2C-NN-NN-NN-B1-2D-1C-B1-2D-1C
CFG-BTV30.2C-P1-2D-1C-NN-NN-NN-NN-NN-NN
CFG-BTV30.2C-P1-2D-A2-1C-NN-NN-NN-NN-NN
CFG-BTV30.2C-P1-2D-A2-2C-NN-NN-NN-NN-NN
CFG-BTV30.2C-TC-B1-2D-1C-NN-NN-NN-NN-NN
CFG-BTV30.2C-TC-B1-2F-A2-A2-2C-NN-NN-1T
CFG-BTV30.2C-TC-B1-2F-A2-A2-A2-2C-NN-1T
CFG-BTV30.2C-TC-BB-S4-B1-2F-A2-1C-NN-NN
CFG-BTV30.2E-2D-1E-NN-NN-NN-NN-NN-NN-NN
CFG-BTV30.2E-2D-A2-1E-NN-NN-NN-NN-NN-NN
CFG-BTV30.2E-B1-2D-1E-B1-2D-NN-NN-NN-NN
CFG-BTV30.2E-B1-2D-1E-NN-NN-NN-NN-NN-1T
CFG-BTV30.2E-B1-2D-1E-NN-NN-NN-NN-NN-NN
CFG-BTV30.2E-B1-2D-2E-NN-NN-NN-NN-NN-NN
CFG-BTV30.2E-B1-2D-A2-1E-NN-NN-NN-NN-NN
CFG-BTV30.2E-P1-2D-1E-NN-NN-NN-NN-NN-NN
CFG-BTV30.2P-TM-NN-NN-NN-NN-NN-NN-NN-1T
CFG-BTV30.2P-TM-NN-NN-NN-NN-NN-NN-NN-NN
CFG-BTV30.2P-TM-TC-NN-NN-NN-NN-NN-NN-1T
CFG-BTV30.2P-TM-TC-NN-NN-NN-NN-NN-NN-NN
CFG-BTV30.2S-2F-NN-NN-NN-NN-NN-NN-NN-NN
CFG-BTV30.2S-B1-2D-NN-NN-NN-NN-NN-NN-1T
CFG-BTV30.2S-P1-2D-NN-NN-NN-NN-NN-NN-NN
CFG-BTV30.2S-P2-P1-2D-NN-NN-NN-NN-NN-NN
CFG-BTV30.2T-TM-VT-NN-NN-NN-NN-NN-NN-NN
FWA-BTV30*-MSD-01VRS-DE
FWA-BTV30*-MSD-01VRS-DE-GBO
FWA-BTV30*-MSD-01VRS-DE-GBO001
FWA-BTV30*-MSD-01VRS-EN
FWA-BTV30*-MSD-01VRS-EN-GBO001
FWA-BTV30*-MSD-01VRS-MS-SON001
FWA-BTV30*-MSD-02VRS-DE-GBO001
FWA-BTV30*-MSD-02VRS-EN-GBO001
FWA-BTV30*-MSD-19VRS-DE-GBO001
FWA-BTV30*-MSD-19VRS-DE-ISP001
FWA-BTV30*-MSD-19VRS-EN-GBO001
FWA-BTV30*-MSD-19VRS-EN-ISP001
FWA-BTV30*-WNT-01VRS-DE
FWA-BTV30*-WNT-01VRS-DE-GBO001
FWA-BTV30*-WNT-01VRS-EN
FWA-BTV30*-WNT-01VRS-EN-GBO001
FWA-BTV30*-WNT-02VRS-DE
FWA-BTV30*-WNT-02VRS-DE-GBO001
FWA-BTV30*-WNT-02VRS-DE-ISP001
FWA-BTV30*-WNT-02VRS-EN
FWA-BTV30*-WNT-02VRS-EN-GBO001
FWA-BTV30*-WNT-19VRS-DE-GBO001
FWA-BTV30*-WNT-19VRS-DE-ISP001
FWA-BTV30*-WNT-19VRS-EN-GBO001
FWA-BTV30*-WNT-19VRS-EN-ISP001
BTV40.2BIC-512P-P8C-NN-FW
BTV40.1AHB-128S-P5C-NN-FW
BTV40.1AHB-256S-P5C-UN-FW
