DKC Drive Controllers
Buy Repair

The DKC Drive Controllers series from Bosch Rexroth Indramat comprises highly versatile drive controllers designed for precision control of position, speed, and torque in industrial automation.

While older models like the DKC01.1 and DKC11.1 emphasize robust diagnostic capabilities for maintenance through a distinctive two-digit H1 display, the newer EcoDrive 03 units, such as the DKC03.3, focus on streamlined installation and operational efficiency. These controllers support a variety of communication interfaces, including SERCOS for high-speed fiber optic data exchange, Profibus for fieldbus integration, and RS232 for direct serial commissioning. The systems utilize advanced feedback mechanisms and internal software synchronization to monitor motor performance and respond instantly to system errors. By integrating comprehensive monitoring of temperatures, voltages, and communication states, the series ensures reliable performance within complex electrical installations.
Type code field What it means How it appears in the code Valid / shown values in the manuals
1) Product family Drive controller family identifier DKC DKC = drive controller
2) Series

Product series number

(varies by generation)

 01, 02, 03, 11 (inside the xx.x block)

Examples:

01.1, 11.1, 02.1, 03.1, 03.3
3) Version

Hardware/version index

within the series

 .1, .3

Examples:

01.1, 02.1, 03.1, 03.3
4) Rated current code Rated output current class encoded as 3 digits -030-, -040-, -100-, -200-, -016-

Examples:

030 = 30 A,

040 = 40 A;

additional shown current codes include

016 (16 A), 100 (100 A), 200 (200 A)
5) DC bus / intermediate circuit voltage class Encoded DC bus (intermediate circuit) nominal voltage class -3- or -7-

Examples: 3 = 300 V, 7 = 700 V

(described as rated intermediate circuit voltage / DC bus nominal voltage / voltage category depending on series)
6) Firmware designator Indicates firmware is required/part of the ordering concept -FW Firmware defines drive functions and is ordered separately



Example type code What you can read directly from it
DKC01.1-040-7-FW Series/Version 01.1, rated current code 040 (=40 A), DC bus class 7 (=700 V), firmware designator FW
DKC11.1-040-7-FW Series/Version11.1, rated current code 040 (=40 A), DC bus class 7 (=700 V), firmware FW
DKC02.1-040-7-FW Series/Version 02.1, rated current code 040 (=40 A), DC bus nominal voltage class 7(=700V), firmware FW
DKC01.1-030-3-FW Series/Version 01.1, rated current code 030 (=30 A), DC bus nominal voltage class 3(=300V) , firmware FW
DKC03.3-040-7-FW Series/Version 03.3, rated current code 040 (=40 A), voltage category 7 (=700V), firmware FW

DKC Drive Controllers
DKC01.1-040-7-FW DKC01.3-004-3-MGP-01VRS DKC01.3-008-3-MGP-01VRS DKC01.3-012-3-MGP-01VRS DKC01.3-016-7-FW DKC01.3-018-3-MGP-01VRS DKC01.3-040-7-FW DKC01.3-100-7-FW DKC01.3-200-7-FW DKC02.1-040-7-FW DKC02.3-004-3-MGP-01VRS DKC02.3-008-3-MGP-01VRS DKC02.3-012-3-MGP-01VRS DKC02.3-016-7-FW DKC02.3-018-3-MGP-01VRS DKC02.3-040-7-FW DKC02.3-100-7-FW DKC02.3-200-7-FW DKC03.3-016-7-FW DKC03.3-100-7-FW DKC03.3-200-7-FW DKC04.3-016-7-FW DKC04.3-040-7-FW DKC04.3-100-7-FW DKC04.3-200-7-FW DKC05.3-040-7-FW DKC05.3-200-7-FW DKC06.3-016-7-FW DKC06.3-040-7-FW DKC06.3-100-7-FW DKC06.3-200-7-FW DKC10.3-004-3-MGP-01VRS DKC10.3-008-3-MGP-01VRS DKC10.3-012-3-MGP-01VRS DKC10.3-018-3-MGP-01VRS DKC11.1-040-7-FW DKC11.3-040-7-FW DKC11.3-100-7-FW DKC11.3-200-7-FW DKC21.3-016-7-FW DKC21.3-040-7-FW DKC21.3-100-7-FW DKC21.3-200-7-FW DKC22.3-016-7-FW DKC22.3-040-7-FW DKC22.3-100-7-FW DKC22.3-200-7-FW FWA-ECODR3-CRP-01VRS-MS FWA-ECODR3-CRP-02VRS-MS FWA-ECODR3-ELC-01VRS-MS FWA-ECODR3-FGP-02VRS-MS FWA-ECODR3-FGP-03VRS-MS FWA-ECODR3-FLP-04VRS-MS FWA-ECODR3-SGP-01VRS-MS FWA-ECODR3-SGP-03VRS-MS FWA-ECODR3-SMT-01VRS-MS FWA-ECODR3-SMT-02VRS-MS DKC03.1-040-7-FW FWA-ECODRV-ASE-02VRS-MS FWA-ECODRV-ASE-04VRS-MS DKC03.3-040-7-FW DKC03.2-100-7-FW DKC01.3-LK-EAK02 DKC02.3-LK-SCK02 DKC03.3-LK-PBK02 DKC04.3-LK-ITB01 DKC06.3-LK-DVN01 DKC05.3-LK-CAN01 DKC05.3-100-7-FW DKC01.1-030-3-FW FWA-ECODR3-FGP-01VRS-MS FWA-ECODR3-SMT-02V45-MS FWA-ECODR3-SMT-03VRS-MS FWA-ECODR3-SGP-02VRS-MS DKC03.3-004-3-MGP-01VRS DKC03.3-008-3-MGP-01VRS DKC03.3-012-3-MGP-01VRS DKC03.3-018-3-MGP-01VRS DKC04.3-004-3-MGP-01VRS DKC04.3-008-3-MGP-01VRS DKC04.3-012-3-MGP-01VRS DKC04.3-018-3-MGP-01VRS DKC05.3-016-7-FW DKC05.3-004-3-MGP-01VRS DKC05.3-008-3-MGP-01VRS DKC05.3-012-3-MGP-01VRS DKC05.3-018-3-MGP-01VRS DKC06.3-004-3-MGP-01VRS DKC06.3-008-3-MGP-01VRS DKC06.3-012-3-MGP-01VRS DKC06.3-018-3-MGP-01VRS DKC01.3-200-7-FW/S100 DKC02.1-030-3-FW DKC10.3-004-3-MGP-01V20 DKC10.3-004-3-MGP-01V22 DKC10.3-004-3-MGP-01V24 DKC10.3-012-3-MGP-01V20 DKC10.3-012-3-MGP-01V22 DKC10.3-012-3-MGP-01V24 DKC11.3-040-7-NW DKC11.3-100-7-NW DKC11.3-200-7-NW DKC21.3-LK-DIO01 DKC22.3-LK-SCP01 FWA-ECODR3-CRP-05VRS-MS FWA-ECODR3-FGP-02V18-MS FWA-ECODR3-FLP-01VRS-MS FWA-ECODR3-FLP-02VRS-MS FWA-ECODR3-FLP-03VRS-MS FWA-ECODR3-FLP-05VRS-MS FWA-ECODR3-SGP-03V28-MS FWA-ECODR3-SMT-02V20-MS FWA-ECODR3-SMT-02V44-D5 FWA-ECODR3-SMT-02V46-D5 FWA-ECODR3-SMT-02V48-D5 FWA-ECODR3-SMT-02V50-D5 FWA-ECODR3-ASE-01VRS-MS DKCXX.3-040-7-FW DKCXX.3-100-7-FW DKCXX.3-200-7-FW DKC02.3-200-7-FW/S10 DKC14.3-040-7-FW DKC14.3-100-7-FW DKC14.3-200-7-FW DKC02.2-100-7-FW FWA-EC00R3-FGP-03VRS -MS SUP-M01-DKCXX.3-040 DKC01.1-040-3-FW SUP-M01-DKCXX.3-100 SUP-M01-DKCXX.3-016 DKCXX.3-640-7-FW DKC01.3-016-7-NN-FW SUP-M01-DKCXX.3-200-7 DKC1.1-030-3 DKC02.3-040-07-FW
