DKC10.3-012-3-MGP-01VRS
MPN: R911295611
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships Today
The DKC10.3-012-3-MGP-01VRS servo drive controller features a selectable switching frequency of 4 or 8 kHz. It delivers a continuous output of 2.5 A with peak current support up to 7.5 A.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
Bosch Rexroth is a renowned manufacturer of industrial automation equipment. They specialize in drives, controllers, and motors for various applications in automation and motion control. Their product range includes servo motors, drive controllers, and hydraulic systems.
The model DKC10.3-012-3-MGP-01VRS is a servo drive controller part of Rexroth's EcoDrive DKC series. This controller operates with a three-phase input and can handle an input voltage range of 200 degrees CE" 240 V. It supports frequencies of 50/60 Hz and features a connected load capacity of 1.2 kVA. It is equipped with a soft-start resistor (RDC) rated at 4.7 Ohms and 17 W which helps manage power surges during startup. The continuous input current varies depending on the voltage, with a maximum of 2.2 A at full load. The controller also supports selectable switching frequencies of 4 or 8 kHz that ensures flexibility in its operation. The maximum inrush current of the controller is dependent on the supply voltage, and the power dissipation is 34.5 W. The model has an inrush current of 37.5 A and a maximum allowed undervoltage of 264 V AC.
The DKC10.3-012-3-MGP-01VRS servo drive controller is capable of delivering a continuous output current of 2.5 A with a peak current of 7.5 A for short durations. Its output frequency ranges between 0 and 333.3 Hz that makes it suitable for a wide range of applications. The device is protected with an IP20 rating. This ensures protection from solid objects and dust. The DKC series servo drive controller operates in ambient temperatures between 0 degrees C to 40 degrees C and has an altitude limitation of 2000 meters above sea level. With built-in protection against vibrations and harsh operating conditions, it is a robust solution for industrial environments.
Frequently Asked Questions about DKC10.3-012-3-MGP-01VRS:
Q: What is the input voltage range for the Bosch Rexroth DKC10.3-012-3-MGP-01VRS servo drive controller?
A: The DKC10.3-012-3-MGP-01VRS operates on a three-phase input with a voltage range of 200-240V. This allows the controller to handle different industrial power environments effectively.
Q: What is the continuous and peak output current for the DKC10.3-012-3-MGP-01VRS?
A: This servo drive controller delivers a continuous output current of 2.5 A. It can also handle a peak current of 7.5 A for short durations, ensuring flexibility for various applications.
Q: What is the protection rating for the DKC10.3-012-3-MGP-01VRS servo drive controller?
A: The DKC10.3-012-3-MGP-01VRS has an IP20 protection rating. This ensures it is safe from dust and solid objects, making it suitable for industrial environments.
Q: What are the environmental operating conditions for the DKC10.3-012-3-MGP-01VRS?
A: This controller operates in temperatures ranging from 0 degrees C to 40 degrees C. It also functions at altitudes of up to 2000 meters, making it adaptable to various conditions.
Q: What are the switching frequency options for the DKC10.3-012-3-MGP-01VRS?
A: The DKC10.3-012-3-MGP-01VRS offers selectable switching frequencies of 4 or 8 kHz. This allows for flexible operation and optimization of performance in various industrial applications.
