DKC10.3-018-3-MGP-01VRS Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911295612
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat DKC10.3-018-3-MGP-01VRS is part of the DKC Drive Controllers series and has a rated current of 18 Amps with a maximum output current of 4.3 Amps. This EcoDrive controller operates on a DC-bus nominal voltage of 300 Volts and features a maximum input current of 3.1 Amps. It offers IP20 ingress protection, supports three input phases, and measures 182 mm in height, 170 mm in depth, and 70 mm in width.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DKC10.3-018-3-MGP-01VRS is an EcoDrive controller produced by Bosch Rexroth Indramat for the DKC Drive Controllers series. It operates as the power conversion link between a three-phase supply and a synchronous servo motor, regulating current, voltage, and carrier frequency so that PLC position or speed commands reach the axis without delay. By modulating the motor phases from its internal DC bus, the unit supports closed-loop motion tasks common in conveyors, pick-and-place gantries, packaging equipment, and other automated handling systems. This makes it suitable for axes that require coordinated speed changes and repeatable positioning during frequent start-stop cycles.
The DC link is held at 300 V, giving the drive a stable energy reservoir for acceleration and regenerative events. Motor windings can be fed with a continuous phase current of 4.3 A, while control signals are reproduced up to 300 Hz so high-speed motors remain within vector control limits. Surplus kinetic energy is routed through an integrated brake element rated at 100 Ω resistance, with 400 Ws capacity and 17 W continuous dissipation, which helps prevent overvoltage on the common bus. A soft-charge network of 4.7 Ω limits inrush when the capacitors energize, protecting upstream circuit breakers and reducing electromagnetic stress. The unit also has a nominal device rating of 18 A, and output line-to-line voltage is capped at 116 V to match low-voltage servo windings.
The housing carries an IP20 ingress rating, so cabinet installation is required. The enclosure is intended for use inside a protected control cabinet rather than direct exposure on the machine. Full output is available until the ambient reaches 55 °C; beyond this point the controller derates to protect its semiconductors. Reliable operation is specified to elevations of 2000 m and relative humidity up to 90 percent without condensation. Weighing 2.1 kg, the unit fits easily into multi-axis racks and occupies 182 mm of height, 70 mm of width, and 170 mm of depth for compact cabinet layouts.
Frequently Asked Questions about DKC10.3-018-3-MGP-01VRS:
Q: What is the nominal DC-bus voltage for the DKC10.3-018-3-MGP-01VRS controller?
A: The DKC10.3-018-3-MGP-01VRS supports a DC-bus nominal voltage of 300 V.
Q: What is the rated current specification of the DKC10.3-018-3-MGP-01VRS?
A: This unit features a rated current of 18 A, enabling it to handle substantial load operations.
Q: What level of ingress protection does the DKC10.3-018-3-MGP-01VRS offer?
A: The DKC10.3-018-3-MGP-01VRS has an ingress protection rating of IP20.
Q: What is the maximum ambient temperature the DKC10.3-018-3-MGP-01VRS can withstand?
A: This model can operate at ambient temperatures up to 55 °C with derating.
Q: What is the continuous power rating for the braking resistor in the DKC10.3-018-3-MGP-01VRS?
A: A braking resistor with a continuous power rating of 17 W is included with this controller.
