DKC10.3-004-3-MGP-01V24

Name: DKC10.3-004-3-MGP-01V24
Brand: Bosch Rexroth Indramat
Price: 385 USD
Availability: InStock
Rating: 4.5 (24 reviews)

Rated 4.5 (24 total ratings)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

MPN: R911333970

In-Stock, Ships Today

The DKC10.3-004-3-MGP-01V24 is a robust and reliable AC servo drive manufactured by Bosch Rexroth Indramat as part of the ECODrive line. The current rating of the unit is 4 A. The DC bus link voltage of the device is 300V DC. The drive incorporates multi-interface general purpose firmware.

Preparing your secure checkout page...

Description
Revisions
Specs
FAQ

Product Description

The DKC10.3-004-3-MGP-01V24 is a servo drive controller produced by Rexroth Indramat. The drive controller is part of the ECODrive line is manufactured with state-of-the-art technology; it provides accurate control for servo motors in industrial servo systems. The DKC10.3-004-3-MGP-01V24 drive controller is flexible in its application; it can be adjusted to suit a broad range of industrial applications such as handing machines, packaging machines, and lots more. The drive controller produces a significant amount of heat during operation; thus, a horizontal minimum installation distance of 10 millimeters and a vertical minimum installation distance of 100 millimeters should be allowed between the drive and other industrial devices nearby. The allowed degree of contamination in the drive is 2, according to EN 50178. The drive housing is produced according to the IP20 protection category; fine dust or moisture condensation should not be allowed to get into the drive, as these particles can interfere with the drive's operation. Servo motors connected to the DKC10.3-004-3-MGP-01V24 drive controller can generate an output current as high as 39.8watts.

The DKC10.3-004-3-MGP-01V24 drive controller has a rated current of 4 amperes; it operates with an input voltage ranging from 200 to 240 volts. Under normal industrial conditions, the DKC10.3-004-3-MGP-01V24 drive controller uses a nominal input current of 1.1 Amperes or 0.7 Amperes depending on the interface through which the drive connects to the mains electricity. The drive features a stop-start resistor, which has a resistance of 4.7 ohms and consumes a continuous power of 17watts. The braking resistor connected to the drive controller can consume a maximum power of 1.68 kilowatts.

The DKC10.3-004-3-MGP-01V24 drive controller should be operated according to the instructions in the drive’s documentation. Only well-skilled technicians should operate or install the drive as poor wiring, wrong customization, and firmware error can lead to machine breakdown or fatal industrial accidents. This unit can be shipped globally with a one-year warranty period from Wake Industrial.

DKC10.3-004-3-MGP-01V24 Technical Specifications

DC-bus nominal voltage:	300 V
Firmware Type:	Multi-interface General Purpose
Firmware Version:	01
Product Type:	DKC Ecodrive
Type Current:	4A
Version:	3

Frequently Asked Questions about DKC10.3-004-3-MGP-01V24

Q: What types of applications is the DKC10.3-004-3-MGP-01V24 servo drive controller suitable for?

A: It is flexible and can be adjusted for a broad range of industrial applications, including handling machines, packaging machines, and many others, providing accurate control for servo motors.

Q: What are the necessary installation clearances for the DKC10.3-004-3-MGP-01V24 to ensure proper operation?

A: Due to heat generation, a horizontal minimum installation distance of 10 millimeters and a vertical minimum installation distance of 100 millimeters should be maintained between the drive and other nearby industrial devices.

Q: What are the input voltage and rated current specifications for this drive controller?

A: The DKC10.3-004-3-MGP-01V24 operates with an input voltage ranging from 200 to 240 volts and has a rated current of 4 amperes

Q: Does the DKC10.3-004-3-MGP-01V24 have internal braking capabilities?

A: Yes, the drive features a stop-start resistor with a resistance of 4.7 ohms (consuming 17 watts continuously), and a connected braking resistor can consume a maximum power of 1.68 kilowatts.

Q: What precautions should be taken regarding the installation and operation of the DKC10.3-004-3-MGP-01V24?

A: Only well-skilled technicians should operate or install the drive, as poor wiring, wrong customization, and firmware errors can lead to machine breakdown or fatal industrial accidents. The drive also has an IP20 protection category, meaning fine dust or moisture condensation should be prevented from entering.

Internal Product Review

‘‘The DKC10.3-004-3-MGP-01V24 is a drive controller manufactured by Bosch Rexroth Indramat. As part of the ECODRIVE series, this makes for a fantastic addition to any control line that requires flexible communication interfaces.’’
