Product Description:

The DKC22.3-LK-SCP01 is a drive controller manufactured by Bosch Rexroth Indramat within the DKC Drive Controllers series. As an EcoDrive unit, it delivers regulated DC power and high-speed communication to servo motors. This supports real-time velocity and position control in automated assembly lines, packaging machinery, and material handling systems. The optical communication arrangement helps keep control data stable in electrically noisy machine environments.

Communication setup is performed over the built-in fiber ring. The configuration switch set to S22 sets the internal station address, allowing deterministic telegram timing on shared media. Data transfer along the optical bus runs at a fixed factory baud rate of 2 Mbit/s, which matches standard SERCOS phase-2 cycles and removes the need for manual bitrate adjustment. Optical transmission begins at port X220, where the unit delivers an output of −4.5 dBm. This level supports reliable detection at downstream drives without oversaturating short cable runs. For glass-core duplex cabling, the permissible reach extends to 500 m, so cabinets can be located far from the motion axis while maintaining noise-immune communication. The link medium is Fiber Optic Cable, which eliminates galvanic coupling between controller backplanes.

The design code 3 marks the hardware revision of the controller. Interface option 22 equips the unit with a second optical channel, and incoming light is accepted at receiver port X221, enabling closed rings that can tolerate a single fiber fault. Where rugged glass links are impractical, the drive can also operate over plastic fibers up to 50 m, providing a quick-fit solution inside compact machines. If telegram synchronization fails, the front-panel STATUS LED switches to a fixed ERROR state for immediate visual indication. This makes link faults easier to identify without additional diagnostic equipment.
