XM21 IndraControl Systems
Buy Repair

The IndraControl XM21 series is a compact Rexroth control platform used as a function package within IndraMotion systems for machine automation in areas such as handling/assembly, packaging, printing, machine tools, and woodworking.

It uses an Intel processor with 512 MB DRAM and provides integrated communications including an Ethernet port plus two Sercos III master/slave interfaces for real-time drive and I/O connectivity. The controller supports modular expansion through an S20 interface that can connect up to 63 S20 I/O modules (100 Mbit/s) and can supply up to 2 A on the S20 bus, with additional extension modules supported via the bus base architecture. Power is supplied from 24 VDC (SELV/PELV) across an 18–31.2 V allowable range, with defined current and power consumption values depending on whether S20 modules are powered from the control. The hardware is intended for installation in a closed control cabinet (IP20 device protection) and is specified for industrial ambient conditions, with defined limits for temperature, humidity (non-condensing), vibration/shock, and EMC operation in industrial environments.

XM21 IndraControl Systems
XM2210.02-04-31-31-101-01 XM2210.01-04-31-31-101-01 XM2100.01-01-31-31-101-NN XM2100.01-01-31-31-001-02-100N3NN XM2100.01-01-31-31-001-NN-100111N XM2100.01-01-31-31-001-NN-100N1NN XM2100.01-01-31-31-001-NN-100N2NN XM2100.01-01-31-31-001-NN-101N3NN XM2100.01-01-31-31-001-NN-102N1NN XM2100.01-01-31-31-001-NN-102N3NN XM2100.01-01-31-31-001-NN-103N1NN XM2100.01-01-31-31-001-NN-103NNNN XM2100.01-01-31-31-001-NN-105NNNN XM2100.01-01-31-31-001-NN-112NNNN XM2100.01-01-31-31-001-NN-115N1NN XM2100.01-01-31-31-301-02-100N1NN XM2100.01-01-31-31-301-NN-10013NN XM2100.01-01-31-31-301-NN-100N2NN XM2100.01-01-31-31-301-NN-101N2NN XM2100.01-01-31-31-301-NN-102N1NN XM2100.01-01-31-31-301-NN-102N3NN XM2100.01-01-31-31-301-NN-103N3NN XM2100.01-01-31-31-301-NN-105N1NN XM2100.01-01-31-31-301-NN-106N1NN XM2100.01-01-31-31-301-NN-106N3NN XM2100.01-01-31-31-301-NN-111N2NN XM2100.01-01-31-31-301-NN-112NNNN XM2100.01-01-31-31-301-NN-113N12N XM2100.01-01-31-31-301-NN-113N1NN XM2100.01-01-31-31-301-NN-113N2NN XM2100.01-01-31-31-301-NN-114NNNN XM2100.01-01-31-31-301-NN-NNNN XM2200.01-01-31-31-001-NN-10013NN XM2200.01-01-31-31-001-NN-1001NNN XM2200.01-01-31-31-001-NN-101N2NN XM2200.01-01-31-31-001-NN-108N3NN XM2200.01-01-31-31-001-NN-112N1NN XM2200.01-01-31-31-001-NN-113N1NN XM2200.01-01-31-31-001-NN-113NNNN XM2200.01-01-31-31-301-NN-1001NNN XM2200.01-01-31-31-301-NN-100N2NN XM2200.01-01-31-31-301-NN-101N2NN XM2200.01-01-31-31-301-NN-104NNNN XM2200.01-01-31-31-301-NN-105N1NN XM2200.01-01-31-31-301-NN-105NNNN XM2200.01-01-31-31-301-NN-111N3NN XM2200.01-01-31-31-301-NN-111NNNN XM2200.01-01-31-31-301-NN-116N1NN XM2200.01-01-31-31-301-NN-131N3NN XM2201.01-01-31-31-301-NN-105N2NN XM2201.01-01-31-31-301-NN-105N3NN XM2201.01-01-31-31-301-NN-105NNNN XM2100.01-01-31-31-001-NN-111NNNN XM2200.01-01-31-31-301-NN-100NNNN XFE01.1-FB-01 XFE01.1-FB-04 XFE01.1-FB-11 XM2100.01-01-31-31-301-NN-113N3NN XM4203.21-21-31-63-301-NN-NNNN-MTXSNNNNN XM4203.21-21-31-63-301-NN-NNNN-MTXPNNNNN XM2100.01-01-31-31-001-NN-100N3NN XM4203.21-21-31-63-301-NN-NNNN-MTXANNNNN XM2200.01-01-31-31-301-NN-108N3NN XM2100.01-01-31-31-301-NN-102NNNN XM2100.01-01-31-31-001-NN-100NNNN XM2100.01-01-31-31-301-NN-100NNNN XM2100.01-01-31-31-301-NN-111NNNN XM2100.01-01-31-31-301-NN-101N1NN XM2100.01-01-31-31-301-NN-108N3NN XM4203.21-21-31-63-301-NN-NNNN-MLCBNNNNN XM2200.01-01-31-31-301-NN-101N3NN XM4203.21-21-31-63-301-NN-NNNN-ILC-NNNNN XM2200.01-01-31-31-301-NN-101NNNN XM2200.01-01-31-31-301-NN-105N3NN XM2200.01-01-31-31-301-NN-100N3NN XFE01.1-SY-01 XM2100.01-01-31-31-001-NN-101NNNN XM2200.01-01-31-31-301-NN-100N1NN XM2100.01-01-31-31-301-NN-100N3NN XM2100.01-01-31-31-001-NN-108N3NN XM2100.01-01-31-31-301-NN-101NNNN XM2200.01-01-31-31-001-NN-111NNNN XFE01.1-FB-20 XM2200.01-01-31-31-001-NN-101NNNN XM2200.01-01-31-31-001-NN-100NNNN XFE01.1-FB-03 XM2100.01-01-31-31-301-NN-101N3NN XFE01.1-FB-10
