BTV20 Machine Operator Panels
Buy Repair

The BTV20 Machine Operator Panels from Bosch Rexroth Indramat comprise a PC-based operator terminal series developed for use on production machines, with a front panel layout intended to support practical machine operation.

The platform combines a Pentium 200 MHz slot CPU with integrated graphics, 64 MB of main memory, a minimum 1.2 GB hard drive, and a 10.4-inch TFT color display with 640 × 480 resolution. For operator input and system connectivity, the series includes a machine-user keyboard with 16 machine function keys, along with RS232, RS232/RS485, VGA, Centronics printer, and Ethernet interfaces. The BTV20 is also designed as an expandable system with nine free slots for modules such as MTC-P, MTS-P, PC104 expansion cards, PLC and CNC modules, PROFIBUS-DP, INTERBUS, RS485, and Ethernet options, while the first slot is reserved for the integrated I/O module. The series is built for industrial installation with an IP65 front panel, AC 115/230 V autorange operation with an available 24 VDC version, and configurable type-code variants covering different function types, keyboard versions, memory capacities, and system configurations.

BTV20 Machine Operator Panels
BTV20.2CA-28B-10D-D-FW BTV20.2CA-28B-11D-D-FW BTV20.2CA-28B-33C-D-FW BTV20.2CA-64B-10C-D-120500-FW BTV20.2CA-64B-10C-D-130500-FW BTV20.2CA-64B-10C-D-FW BTV20.2CA-64B-10D-D-FW BTV20.2CA-64B-11C-D-FW BTV20.2CA-64B-33C-D-FW BTV20.2EA-28B-10C-D-FW BTV20.2EA-28B-10D-D-FW BTV20.2EA-28B-11C-D-FW BTV20.2EA-28B-11D-D-FW BTV20.2EA-64B-10C-D-FW BTV20.2EA-64B-10D-D-FW BTV20.2EA-64B-11D-D-FW BTV20.2EA-64B-33C-D-FW BTV20.2PA-24B-55D-E-NW BTV20.2PA-64B-10C-D-000000-FW BTV20.2PA-64B-10C-D-FW BTV20.2PA-64B-10D-D-FW BTV20.2PA-64B-11D-D-FW BTV20.2PA-64B-33C-D-FW BTV20.2SA-24B-55D-D-FW BTV20.2SA-28B-10C-D-FW BTV20.2SA-28B-10D-D-FW BTV20.2SA-28B-11C-D-FW BTV20.2SA-28B-11D-D-FW BTV20.2SA-64B-10C-D-FW BTV20.2SA-64B-10D-D-FW BTV20.3AA-28B-33C-D-FW BTV20.3AA-28B-44C-D-FW BTV20.3AA-28B-45C-D-FW BTV20.3AA-56B-44C-D-FW BTV20.3AA-56B-45C-D-FW BTV20.3AA-64B-33C-D-FW BTV20.3CA-24B-55C-D-FW BTV20.3CA-28B-33C-D-FW BTV20.3CA-28B-33C-S-FW BTV20.3CA-28B-44C-D-FW BTV20.3CA-28B-45C-D-FW BTV20.3CA-56B-44C-D-FW BTV20.3CA-56B-45C-D-FW BTV20.3CA-64B-33C-D-FW BTV20.3EA-24B-55C-D-FW BTV20.3EA-24B-55C-S-FW BTV20.3EA-28B-33C-D-FW BTV20.3EA-28B-33C-S-FW BTV20.3EA-28B-44C-D-FW BTV20.3EA-28B-44C-S-FW BTV20.3EA-28B-45C-D-FW BTV20.3EA-56B-33C-S-FW BTV20.3EA-56B-44C-D-FW BTV20.3EA-56B-45C-D-FW BTV20.3EA-56B-45C-S-FW BTV20.3EA-64B-33C-D-FW BTV20.3PA-24B-55C-D-FW BTV20.3PA-24B-55C-D-NW BTV20.3PA-24B-55C-E-NW BTV20.3PA-28B-33C-D-FW BTV20.3PA-28B-33C-S-FW BTV20.3PA-28B-44C-D-FW BTV20.3PA-28B-44C-S-FW BTV20.3PA-28B-45C-D-FW BTV20.3PA-28B-45C-S-FW BTV20.3PA-56B-45C-D-FW BTV20.3PA-56B-45C-S-FW BTV20.3PA-64B-33C-D-FW BTV20.3PA-64B-33C-D-NW BTV20.3SA-24B-55C-D-FW BTV20.3SA-24B-55C-S-FW BTV20.3SA-28B-33C-D-FW BTV20.3SA-28B-33C-S-FW BTV20.3SA-28B-44C-D-FW BTV20.3SA-28B-45C-D-FW BTV20.3SA-56B-33C-S-FW BTV20.3SA-56B-45C-D-FW BTV20.3SA-56B-45C-S-FW BTV20.3SA-64B-33C-D-FW BTV20.4AA-24B-55C-D-FW BTV20.4AA-24B-55C-E-FW BTV20.4AA-56B-45C-D-FW CFG-BTV20.2C-B1-2D-1C-NN-NN-NN-NN-NN-NN CFG-BTV20.2C-B1-2D-A2-1C-NN-NN-NN-NN-1T CFG-BTV20.2C-BB-S4-B1-2F-1C-NN-NN-NN-NN CFG-BTV20.2C-BB-S4-B1-2F-A2-1C-NN-NN-NN CFG-BTV20.2C-E1-B1-1S-1C-1T-NN-NN-NN-NN CFG-BTV20.2C-E1-B1-1S-1C-NN-NN-NN-NN-NN CFG-BTV20.2C-E1-B1-2D-A2-1C-NN-NN-NN-NN CFG-BTV20.2C-E1-B1-2D-A2-2C-NN-NN-NN-1T CFG-BTV20.2C-E1-P1-2D-A2-2C-NN-NN-NN-1T CFG-BTV20.2C-E1-S4-B1-2D-1C-NN-NN-NN-1T CFG-BTV20.2P-TB-NN-NN-NN-NN-NN-NN-NN-1T CFG-BTV20.2S-E1-P1-1M-NN-NN-NN-NN-NN-NN CFG-BTV20.2S-E1-P1-2M-NN-NN-NN-NN-NN-NN CFG-BTV20.3A-1F-BB-S4-B1-2D-2L-1L-1N-1V CFG-BTV20.3A-1F-BB-S4-B1-2F-2L-1L-1N-1V CFG-BTV20.3A-1F-NN-B1-2D-3L-2L-1L-1N-1V CFG-BTV20.3A-1F-NN-B1-2F-3L-2L-1L-1N-1V CFG-BTV20.3A-1F-NN-NN-B1-2D-2L-1L-1N-1V CFG-BTV20.3A-1F-NN-NN-B1-2D-NN-1L-1N-1V CFG-BTV20.3A-1F-NN-NN-B1-2F-2L-1L-1N-1V CFG-BTV20.3A-1F-NN-NN-P1-2D-2L-1L-1N-1V CFG-BTV20.3A-1F-NN-NN-P1-2F-2L-1L-1N-1V CFG-BTV20.3A-1F-NN-P1-2F-3L-2L-1L-1N-1V CFG-BTV20.3A-1F-NN-P1-B1-2D-NN-1L-1N-1V CFG-BTV20.3A-NN-NN-NN-NN-NN-NN-NN-NN-NN CFG-BTV20.3C-NN-2T-2T-B1-2D-2C-NN-NN-NN CFG-BTV20.3C-NN-2T-2T-P1-B1-2F-A2-2C-NN CFG-BTV20.3C-NN-2T-BB-S4-B1-2D-2C-NN-NN CFG-BTV20.3C-NN-2T-BB-S4-B1-2D-A2-2C-NN CFG-BTV20.3C-NN-2T-BB-S4-B1-2F-2C-NN-NN CFG-BTV20.3C-NN-2T-BB-S4-B1-2F-A2-2C-NN CFG-BTV20.3C-NN-2T-BB-S4-B1-B1-2F-2C-NN CFG-BTV20.3C-NN-2T-BB-S4-P1-2F-A2-2C-NN CFG-BTV20.3C-NN-2T-BB-S4-P1-B1-2D-2C-NN CFG-BTV20.3C-NN-2T-E1-B1-2D-2C-NN-NN-NN CFG-BTV20.3C-NN-2T-E1-B1-2D-A2-2C-NN-NN CFG-BTV20.3C-NN-2T-E1-B1-2D-A2-A2-2C-NN CFG-BTV20.3C-NN-2T-E1-P1-2D-A2-2C-NN-NN CFG-BTV20.3C-NN-2T-E1-P1-2D-A2-A2-2C-NN CFG-BTV20.3C-NN-2T-E1-P1-B1-2D-2C-NN-NN CFG-BTV20.3C-NN-2T-E1-P1-B1-2D-A2-2C-NN CFG-BTV20.3C-NN-2T-E1-S4-B1-2D-A2-2C-NN CFG-BTV20.3C-NN-2T-NN-B1-2D-2C-NN-NN-NN CFG-BTV20.3C-NN-2T-NN-B1-2D-A2-2C-NN-NN CFG-BTV20.3C-NN-2T-NN-B1-2D-A2-A2-2C-NN CFG-BTV20.3C-NN-2T-NN-B1-2F-2C-NN-NN-NN CFG-BTV20.3C-NN-2T-NN-B1-2F-A2-2C-NN-NN CFG-BTV20.3C-NN-2T-NN-B1-2F-A2-A2-2C-NN CFG-BTV20.3C-NN-2T-NN-B1-2F-A2-A2-A2-2C CFG-BTV20.3C-NN-2T-NN-NN-2D-2C-NN-NN-NN CFG-BTV20.3C-NN-2T-NN-P1-2D-2C-NN-NN-NN CFG-BTV20.3C-NN-2T-NN-P1-2D-A2-2C-NN-NN CFG-BTV20.3C-NN-2T-NN-P1-2F-2C-NN-NN-NN CFG-BTV20.3C-NN-2T-P1-B1-2D-2C-NN-NN-NN CFG-BTV20.3C-NN-2T-P1-B1-2D-A2-2C-NN-NN CFG-BTV20.3C-NN-2T-P2-B1-2D-2C-NN-NN-NN CFG-BTV20.3C-NN-2T-P2-P1-2F-2C-NN-NN-NN CFG-BTV20.3C-NN-BB-S4-B1-2D-2C-NN-NN-NN CFG-BTV20.3C-NN-BB-S4-B1-2D-A2-2C-NN-NN CFG-BTV20.3C-NN-BB-S4-B1-2F-2C-NN-NN-NN CFG-BTV20.3C-NN-BB-S4-B1-2F-A2-2C-NN-NN CFG-BTV20.3C-NN-BB-S4-P1-2D-2C-NN-NN-NN CFG-BTV20.3C-NN-BB-S4-P1-2F-A2-2C-NN-NN CFG-BTV20.3C-NN-BB-S4-P1-B1-2D-A2-2C-NN CFG-BTV20.3C-NN-BB-S4-P1-B1-2F-A2-2C-NN CFG-BTV20.3C-NN-E1-S4-B1-2D-2C-NN-NN-NN CFG-BTV20.3C-NN-E1-S4-B1-2D-A2-2C-NN-NN CFG-BTV20.3C-NN-E1-S4-B1-2F-2C-NN-NN-NN CFG-BTV20.3C-NN-E1-S4-B1-2F-A2-2C-NN-NN CFG-BTV20.3C-NN-NN-E1-B1-2D-2C-NN-NN-NN CFG-BTV20.3C-NN-NN-E1-B1-2D-A2-2C-NN-NN CFG-BTV20.3C-NN-NN-NN-B1-2D-2C-NN-NN-NN CFG-BTV20.3C-NN-NN-NN-B1-2D-A2-2C-NN-NN CFG-BTV20.3C-NN-NN-NN-B1-2F-2C-NN-NN-NN CFG-BTV20.3C-NN-NN-NN-P1-2D-2C-NN-NN-NN CFG-BTV20.3C-NN-NN-NN-P1-2D-A2-2C-NN-NN CFG-BTV20.3C-NN-NN-NN-P1-2F-2C-NN-NN-NN CFG-BTV20.3C-NN-NN-P1-B1-2F-2C-NN-NN-NN CFG-BTV20.3C-PA-2T-P1-B1-2F-2C-NN-NN-NN CFG-BTV20.3E-NN-2T-2T-P1-B1-2F-A2-2E-NN CFG-BTV20.3E-NN-2T-2T-P1-B1-2F-A3-1P-NN CFG-BTV20.3E-NN-2T-B1-B1-4F-2E-NN-NN-NN CFG-BTV20.3E-NN-2T-BB-S4-2D-A2-2E-NN-NN CFG-BTV20.3E-NN-2T-BB-S4-B1-2D-2E-NN-NN CFG-BTV20.3E-NN-2T-BB-S4-B1-2F-2E-NN-NN CFG-BTV20.3E-NN-2T-BB-S4-P1-B1-2F-2E-NN CFG-BTV20.3E-NN-2T-E1-B1-2D-A2-2E-NN-NN CFG-BTV20.3E-NN-2T-NN-B1-2D-2E-NN-NN-NN CFG-BTV20.3E-NN-2T-NN-B1-2D-A2-2E-NN-NN CFG-BTV20.3E-NN-2T-NN-B1-2F-2E-NN-NN-NN CFG-BTV20.3E-NN-2T-NN-B1-2F-A2-2E-NN-NN CFG-BTV20.3E-NN-2T-NN-B1-2F-A2-A2-A2-2E CFG-BTV20.3E-NN-2T-NN-B1-4F-2E-NN-NN-NN CFG-BTV20.3E-NN-2T-NN-NN-2D-2E-NN-NN-NN CFG-BTV20.3E-NN-2T-NN-P1-2F-2E-NN-NN-NN CFG-BTV20.3E-NN-2T-NN-P1-2F-A2-2E-NN-NN CFG-BTV20.3E-NN-2T-P1-B1-2F-2E-NN-NN-NN CFG-BTV20.3E-NN-2T-P2-P1-2D-2E-NN-NN-NN CFG-BTV20.3E-NN-2T-P2-P1-2D-A2-A2-2E-NN CFG-BTV20.3E-NN-2T-P2-P1-2D-A2-A2-A2-2E CFG-BTV20.3E-NN-BB-S4-B1-2D-A2-2E-NN-NN CFG-BTV20.3E-NN-BB-S4-B1-2D-A2-A2-A2-2E CFG-BTV20.3E-NN-BB-S4-B1-2F-2E-NN-NN-NN CFG-BTV20.3E-NN-NN-B1-B1-2F-A2-2E-NN-NN CFG-BTV20.3E-NN-NN-E1-B1-2D-A2-2E-NN-NN CFG-BTV20.3E-NN-NN-NN-B1-2D-2E-NN-NN-NN CFG-BTV20.3E-NN-NN-NN-B1-2D-A2-2E-NN-NN CFG-BTV20.3E-NN-NN-NN-B1-2F-2E-NN-NN-NN CFG-BTV20.3E-NN-NN-NN-B1-2F-A2-2E-NN-NN CFG-BTV20.3E-NN-NN-NN-B1-2F-A2-A2-2E-NN CFG-BTV20.3E-NN-NN-NN-B1-2F-A2-A2-A2-2E CFG-BTV20.3E-NN-NN-NN-B1-2F-A3-1P-NN-NN CFG-BTV20.3E-NN-NN-NN-NN-2D-A2-2E-NN-NN CFG-BTV20.3E-NN-NN-NN-P1-2D-2E-NN-NN-NN CFG-BTV20.3E-NN-NN-NN-P1-2D-A2-2E-NN-NN CFG-BTV20.3E-NN-NN-NN-P1-2F-2E-NN-NN-NN CFG-BTV20.3E-NN-NN-NN-P1-2F-A2-2E-NN-NN CFG-BTV20.3E-NN-NN-NN-P1-4F-2E-NN-NN-NN CFG-BTV20.3E-NN-NN-NN-P1-4F-A3-1P-NN-NN CFG-BTV20.3E-NN-NN-P2-P1-2D-2E-NN-NN-NN CFG-BTV20.3P-NN-2T-NN-NN-TB-NN-NN-NN-NN CFG-BTV20.3P-NN-NN-NN-NN-TB-NN-NN-NN-NN CFG-BTV20.3S-NN-2T-2T-B1-2D-NN-NN-NN-NN CFG-BTV20.3S-NN-2T-2T-B1-2F-NN-NN-NN-NN CFG-BTV20.3S-NN-2T-2T-BB-S4-B1-2F-NN-NN CFG-BTV20.3S-NN-2T-2T-E1-B1-2D-NN-NN-NN CFG-BTV20.3S-NN-2T-B1-B1-4F-NN-NN-NN-NN CFG-BTV20.3S-NN-2T-BB-S4-B1-2D-NN-NN-NN CFG-BTV20.3S-NN-2T-BB-S4-B1-2F-NN-NN-NN CFG-BTV20.3S-NN-2T-BB-S4-B1-B1-2F-NN-NN CFG-BTV20.3S-NN-2T-BB-S4-B1-B1-4F-NN-NN CFG-BTV20.3S-NN-2T-BB-S4-P1-2D-NN-NN-NN CFG-BTV20.3S-NN-2T-BB-S4-P1-B1-2F-NN-NN CFG-BTV20.3S-NN-2T-BB-S4-P1-B1-4F-NN-NN CFG-BTV20.3S-NN-2T-BB-S4-P2-B1-2F-NN-NN CFG-BTV20.3S-NN-2T-E1-B1-2F-NN-NN-NN-NN CFG-BTV20.3S-NN-2T-NN-B1-2D-NN-NN-NN-NN CFG-BTV20.3S-NN-2T-NN-B1-2F-NN-NN-NN-NN CFG-BTV20.3S-NN-2T-NN-B1-4F-NN-NN-NN-NN CFG-BTV20.3S-NN-2T-NN-P1-2D-NN-NN-NN-NN CFG-BTV20.3S-NN-2T-NN-P1-2F-NN-NN-NN-NN CFG-BTV20.3S-NN-2T-P1-B1-2F-NN-NN-NN-NN CFG-BTV20.3S-NN-2T-P1-B1-4F-NN-NN-NN-NN CFG-BTV20.3S-NN-2T-P2-B1-2F-NN-NN-NN-NN CFG-BTV20.3S-NN-BB-S4-B1-2D-NN-NN-NN-NN CFG-BTV20.3S-NN-BB-S4-P1-2D-NN-NN-NN-NN CFG-BTV20.3S-NN-BB-S4-P1-2F-NN-NN-NN-NN CFG-BTV20.3S-NN-NN-NN-B1-2D-NN-NN-NN-NN CFG-BTV20.3S-NN-NN-NN-B1-2F-NN-NN-NN-NN CFG-BTV20.3S-NN-NN-NN-P1-2D-NN-NN-NN-NN CFG-BTV20.3S-NN-NN-NN-P1-2F-NN-NN-NN-NN CFG-BTV20.3S-NN-NN-P1-B1-2F-NN-NN-NN-NN CFG-BTV20.4A-2V-NN-NN-2N-NN-B1-2D-PC-1G CFG-BTV20.4A-2V-NN-NN-2N-NN-B1-2F-PC-1G CFG-BTV20.4A-2V-NN-NN-2N-NN-P1-2F-PC-1G CFG-BTV20.4A-2V-NN-NN-3N-4L-B1-2D-PC-1G CFG-BTV20.4A-2V-NN-NN-3N-4L-B1-2F-PC-1G CFG-BTV20.4A-2V-NN-NN-3N-4L-P1-2F-PC-1G CFG-BTV20.4A-NN-NN-NN-2N-NN-B1-2D-PC-1G CFG-BTV20.4A-NN-NN-NN-3N-4L-B1-2D-PC-1G FWA-BTV*33-WNT-04VRS-DE-OEM FWA-BTV*44-WNT-04VRS-DE-OEM FWA-BTV*55-GHO-01V00-DE-OEM FWA-BTV*55-WNT-04VRS-DE-OEM FWA-BTV20*-MSD-01VRS-EN FWA-BTV20*-MSD-01VRS-EN-GBO001 FWA-BTV20*-MSD-01VRS-EN-ISP001 FWA-BTV20*-MSD-19VRS-EN-GBO001 FWA-BTV20*-MSD-19VRS-EN-ISP001 FWA-BTV20*-WNS-01VRS-DE-HMI002 FWA-BTV20*-WNS-01VRS-EN-HMI001 FWA-BTV20*-WNS-19VRS-DE-HMI001 FWA-BTV20*-WNS-19VRS-DE-HMI002 FWA-BTV20*-WNS-19VRS-EN-HMI001 FWA-BTV20*-WNS-19VRS-EN-HMI002 FWA-BTV20*-WNT-01VRS-DE FWA-BTV20*-WNT-01VRS-DE-GBO001 FWA-BTV20*-WNT-01VRS-DE-HMI001 FWA-BTV20*-WNT-01VRS-DE-HMI002 FWA-BTV20*-WNT-01VRS-EN FWA-BTV20*-WNT-01VRS-EN-GBO001 FWA-BTV20*-WNT-01VRS-EN-HMI001 FWA-BTV20*-WNT-01VRS-EN-HMI002 FWA-BTV20*-WNT-01VRS-EN-MT*PF070 FWA-BTV20*-WNT-19VRS-DE-GBO001 FWA-BTV20*-WNT-19VRS-DE-HMI001 FWA-BTV20*-WNT-19VRS-DE-HMI002 FWA-BTV20*-WNT-19VRS-DE-ISP001 FWA-BTV20*-WNT-19VRS-EN-GBO001 FWA-BTV20*-WNT-19VRS-EN-HMI001 FWA-BTV20*-WNT-19VRS-EN-HMI002 FWA-BTV20*-WNT-19VRS-EN-ISP001 FWA-BTV203-WNS-19VRS-DE-HMI001 FWA-BTV203-WNS-19VRS-DE-HMI002 FWA-BTV203-WNS-19VRS-DE-IS*PF090 FWA-BTV203-WNS-19VRS-DE-MT*PF090 FWA-BTV203-WNS-19VRS-EN-HMI001 FWA-BTV203-WNS-19VRS-EN-HMI002 FWA-BTV203-WNT-01VRS-DE FWA-BTV203-WNT-01VRS-DE-MTA001 FWA-BTV203-WNT-01VRS-DE-MTA002 FWA-BTV203-WNT-01VRS-EN FWA-BTV203-WNT-01VRS-EN-HMI001 FWA-BTV203-WNT-01VRS-EN-MA*PF070 FWA-BTV203-WNT-01VRS-EN-MTA001 FWA-BTV203-WNT-01VRS-EN-MTA002 FWA-BTV203-WNT-19VRS-DE-GBO001 FWA-BTV203-WNT-19VRS-DE-HMI001 FWA-BTV203-WNT-19VRS-DE-HMI002 FWA-BTV203-WNT-19VRS-DE-IS*PF090 FWA-BTV203-WNT-19VRS-DE-ISP001 FWA-BTV203-WNT-19VRS-DE-MT*PF090 FWA-BTV203-WNT-19VRS-EN-GBO001 FWA-BTV203-WNT-19VRS-EN-HMI001 FWA-BTV203-WNT-19VRS-EN-HMI002 FWA-BTV203-WNT-19VRS-EN-ISP001 BTV20.2CA-64B-11D-D-FW BTV20.3CA-2BB-45C-D-FW BTV20.3S-NN-2T-NN-B1-4F-NN-NN-NN-NN BTV20/30 PC Slot-ETXP3-700
