The Beckhoff AL linear motor series is a versatile, high-performance family of direct-drive linear servomotors engineered for dynamic industrial motion applications.
It spans three standard widths (50, 80, and 130 mm) with a wide array of motor variants, providing peak forces from ~120 N up to 6,750 N and top speeds around 10–12 m/s to meet diverse application needs. A key design feature is its modular coil concept: each motor is built from identical coil segments, allowing flexible length customization and creating a precisely symmetrical structure that simplifies mechanical integration with uniform mounting dimensions; this balanced design also yields even force distribution and efficient cooling without hot spots for reliable continuous operation. Optimized for smart manufacturing, an optional One Cable Technology (OCT) version consolidates power, feedback, and thermal sensor connections into a single cable, drastically simplifying wiring and commissioning via an electronic nameplate; the motors also interface seamlessly with Beckhoff’s EtherCAT-based servo drive systems (AX5000/AX8000) without the need for extra hardware like connector boxes, enabling plug-and-play integration into advanced automation environments. Overall, the AL series combines adaptability, efficiency, and reliability – from its cooling-optimized design to its integration-friendly features.
