Bosch Rexroth Indramat IndraControl Series

Bosch Rexroth’s Indramat IndraControl product line encompasses a wide range of industrial operator panels and programmable controllers designed for high reliability and flexibility in automation systems​. These include IndraControl V series operator terminals – such as the VCP, VEP, VPP, and VSP panels – as well as IndraControl L series controllers like the IndraControl L20 and L25 PLCs. All IndraControl devices are engineered for seamless integration into complex industrial environments, offering robust performance and advanced features to meet demanding machine control needs​.

IndraControl VCP Series – Compact Operator Terminals

The IndraControl VCP (Visual Control Panel) series consists of extremely compact operator terminals used for machine-level control and monitoring​. Each VCP unit integrates a Small Operator Terminal (SOT) interface – essentially a built-in HMI for initiating machine functions and navigating menus​. Despite their small size, VCP panels combine flexible hardware configurations with cost-effective visualization capabilities​. Key characteristics of the VCP series include:

Display & Interface

 Early models like VCP01 and VCP02 feature monochrome or low-resolution graphic LCDs with simple membrane or short-stroke keypads for input​. Newer models introduce higher resolutions – for instance, the IndraControl VCP 05 has a 120×32-pixel graphic display, and the VCP08 offers a 240×128 pixel full-graphic display with more function keys for versatile control​. The largest of the series, VCP20 and VCP25, provide an even higher resolution, up to 320×240 pixels, and other display features; notably, the VCP25 includes a 5.7″ color touchscreen interface instead of physical keys, making it the most advanced panel in the VCP lineup​.

Memory & Performance

 All VCP terminals run on 24 V DC power and are built around dedicated controller-based HMI hardware. They come with onboard application memory. Typically, 256 kB for VCP01–VCP20, expanded up to 3 MB in the VCP25 for storing interface programs​. Firmware is stored in flash memory, anywhere from 256 kB to 768 kB depending on the model, and CMOS RAM (battery-buffered) is used for system data​. For example, the VCP08-2DTN-003-SR-NN-PW variant (a specific model of VCP08) uses an ARM9 or Z84 CPU and provides about 16 MB flash and 3 MB user memory to run the HMI application​. These resources ensure responsive operation of the panel’s user interface and any onboard diagnostics.

Key Functions

VCP panels with physical buttons offer numerous programmable function keys and system keys for navigation. A VCP08 typically has around 14 function keys whereas smaller VCPs have fewer, usually around 8 function keys on VCP05 or lower. The keys are ruggedized – built on aluminum front panels with protective polyester overlays – to withstand industrial use​. This design provides operators with tactile feedback and durability in harsh settings; the front panels are rated up to IP54/IP65 on many models.

Connectivity

 Depending on the model, IndraControl VCP units can be equipped with serial communication ports and/or fieldbus interfaces for connecting to the main control system. Smaller units like VCP01 may have a single RS-232 port​, while more advanced units support multiple ports. For instance, the VCP08 is available in variants offering up to three serial interfaces or an optional fieldbus module like DeviceNet, PROFIBUS-DP, or INTERBUS, for integration into various networks​. This flexibility allows the VCP series to serve as either a simple local operator panel or a networked HMI node on the factory floor.

Overall, the VCP series provides reliable and compact operator panels for machine control, with models ranging from the basic text displays of the VCP01/VCP02 to the touchscreen-enabled VCP25. Wake Industrial can supply unused surplus or refurbished VCP units across the entire range – including hard-to-find models like the VCP05 and VCP08 – to keep your legacy Rexroth Indramat systems running smoothly. All VCP units purchased from Wake Industrial come tested and backed by warranty, ensuring they perform to original specs on your equipment. Request a quote now by using the form or calling 1‑919‑443‑0207 to speak with Wake Industrials automation experts.

IndraControl VEP Series – High-Performance Embedded Panels

The IndraControl VEP series consists of “embedded” operator terminals – essentially industrial PCs designed as compact HMI panels. These panels are more powerful than the VCP series and are intended for graphically rich or computation-heavy interface tasks in industries like packaging, printing, and food processing​. IndraControl VEP panels typically run on embedded operating systems, such as Windows CE, and offer larger displays with touch input, making them suitable for complex applications that a small text panel could not handle​. Key features of the VEP series include:

• PC-Based Architecture: Unlike the controller-based VCP units, VEP terminals are PC-based HMIs built on x86 processors. For example, a typical model like the IndraControl VEP50 is equipped with an Intel Celeron 600 MHz processor along with 256 MB of RAM, running Windows CE 4.2 as its operating system​. This architecture allows VEP panels to support advanced graphics and even act as soft-PLCs or local data processors, extending the functionality beyond simple display. The use of Windows Embedded OS provides a familiar platform for developing custom HMI applications while ensuring real-time performance for control tasks.
• Display & Input: VEP series panels come in various screen sizes to accommodate different use cases. The VEP30 is a mid-sized unit with an 8.4” display, whereas larger models like VEP40 and VEP50 offer screens up to 15″. For instance, the VEP50.1CHU-064NN-G3D-064-EC-FW  features a 15-inch TFT touchscreen with 1024×768 XGA resolution​, delivering sharp visuals for detailed monitoring. A virtual on-screen keyboard is available for operator input, and some VEP variants may also include external keyboard/mouse connectivity if needed. The front panels are robustly built and rated IP65 at the front, meaning they are dust-tight and protected against water jets – suitable for washdown or dusty industrial environments​.
• Memory & Storage: Being PC-based, IndraControl VEP units have significantly more memory and storage than VCP terminals. They typically incorporate flash storage and backup memory for reliability. The VEP50 includes dual CompactFlash slots (with one 128 MB CF card installed for the OS/software) and a short-term UPS that provides 512 kB of buffered memory to preserve data in case of power loss​. This ensures critical information or machine state can be retained to the non-volatile memory during an outage.
• Connectivity: IndraControl VEP panels are equipped with a range of built-in interfaces for communication and expansion. Common interfaces include Ethernet TCP/IP, RS-232 serial ports, and multiple USB ports for connecting peripheral devices​. This connectivity enables the VEP panel to link with PLC controllers, download recipes or production data over a network, and interface with USB devices. In addition, VEP units often have VGA or DVI outputs to drive external displays, and other industrial communication ports can be present depending on model (e.g. some support PROFIBUS or other fieldbuses via internal modules). All these features make the VEP series a high-performance HMI solution that can serve as a central operator station on complex equipment.

Because of their capabilities, VEP panels are ideal for tasks requiring rich graphics or PC-like processing in an HMI. They strike a balance between the simple VCP units and the fully loaded panel PCs (VSP/VPP series) by using embedded OS and moderate hardware to achieve reliability. Wake Industrial offers comprehensive support for the IndraControl VEP range, from sourcing surplus VEP30 and VEP50 units to providing expert repair services. If your production line relies on a VEP embedded terminal, Wake Industrial can quickly provide a replacement or fix your faulty unit – minimizing downtime for your operation. Just call 1‑919‑443‑0207 to learn how Wake Industrial can meet your automation needs.

IndraControl VSP and VPP Series – Advanced PC-Based HMI Panels

At the top end of the IndraControl HMI family are the VSP and VPP series panels. These are fully-fledged PC-based HMIs that deliver the performance of an industrial computer in the form factor of a panel. Introduced as part of Rexroth’s IndraControl V family for applications needing powerful computing and multi-touch interfaces, the VSP & VPP series are built to handle complex visualization, data processing, and even control functions on the factory floor​. Both series share a common platform but are tailored to different operational environments: IndraControl VSP panels are the standard, economical solution for general industry, while IndraControl VPP panels are enhanced for high-stress conditions (vibration, shock, etc.)​. Key technical highlights of VSP/VPP panel PCs include:

• Powerful Hardware: VSP & VPP panels integrate high-speed processors and ample memory to run advanced HMI software or even Windows-based control programs. They typically use Intel Celeron or Pentium-class CPUs around 2.0 GHz, coupled with up to 2 GB of RAM, four times the memory of previous generation panels. For storage, these units provide hard drives to store operating systems (Windows XP or Windows 7 Embedded) and application data, with options for solid-state drives (SSD) for improved reliability​. The internal PC hardware also features dedicated graphics controllers, with up to 8 MB video memory, to ensure smooth display performance​. Essentially, a VSP or VPP panel is an industrial computer inside a rugged HMI enclosure – capable of running SCADA software, multi-touch UI applications, and complex control algorithms directly on the machine.
• Display & User Interface: IndraControl VSP and VPP panels are available in a range of display sizes from ~12 inches to 17 inches, with both touchscreen and hard-key variants to suit user preferences​. For example, the VSP16.1BKE-1G0NN-C1C-AN-NN-FW model typically has a 12″ TFT touchscreen (600×800 SVGA resolution, 256k colors) while the larger VSP40.1DEE-512NN-C1C-AD-NN-FW model offers a 15″ XGA display (1024×768 pixels)​. Multi-touch capacitive touchscreens are supported on newer VPP variants, enabling intuitive gesture controls and more interactive HMIs. On the other hand, some VSP & VPP units include a physical keypad with machine function keys for operators who prefer tactile feedback​. The keypad versions use a thick aluminum front panel with embossed, chemical-resistant keys (IP65-rated front) to endure heavy use​. All variants have high-brightness, wide-view displays to ensure readability in industrial lighting. A USB port on the front panel is also provided on many models, allowing quick connection of USB sticks, keyboards, or other accessories for maintenance and data transfer​.
• Rugged Construction: Both VSP and VPP series are built for harsh industrial environments, but the IndraControl VPP models include extra ruggedization for extreme conditions. VPP panels feature special vibration-dampening hard disk mounts and can withstand operational vibration up to 1g and shock up to 5g​. In contrast, the VSP series is rated for standard factory floor conditions (vibration ~0.25g, shock 5g​.) Both series carry at least IP65 front protection against dust and water, with wide operating temperature ranges of 0°C to +45°C. The compact design of these newer panels is notable – they are about 1.5 inches thinner than earlier generation panel PCs, making them easier to install in tight machine enclosures​. The units can operate on universal AC power (90–264 V AC) or 24 V DC, providing flexibility in different control cabinet power schemes​.
• Connectivity & Expansion: IndraControl VSP & VPP panel PCs come with a rich set of I/O and expansion slots, effectively matching a typical industrial PC. Standard interfaces include Ethernet (10/100Base-T), multiple USB 2.0 ports, RS-232 serial, PS/2 for keyboard/mouse, and even a VGA output for an external monitor​. Many models also have a parallel port and support for fieldbus connectivity (some units can serve as Profibus masters or interface with other PLC networks via add-in cards). In fact, each VSP/VPP panel contains 6 PCI expansion slots on its PC motherboard​ – this means additional cards for motion control, additional network interfaces, or custom I/O can be installed, tailoring the panel PC to the machine’s needs. Such expandability is a huge advantage for integrators, as the HMI panel can also incorporate control functions, safety interlocks, or data acquisition cards, reducing the need for separate PCs or controllers. The panels support hot swapping in some configurations (the entire panel can be replaced quickly without complex reconfiguration.)

In summary, the VSP and VPP series are high-end IndraControl HMIs that deliver PC-level performance on the plant floor. They are ideal for applications like large machine line control, supervisory interfaces, or any scenario requiring a rugged industrial PC with an integrated display – examples include automotive assembly stations, gantry/robot controls, printing and converting machines, and more​. Wake Industrial recognizes the critical role of these advanced panels and offers fast turnarounds on repairs and replacements. Whether you need a surplus VSP16 or VSP40 panel PC to replace a failing unit, or require a repair of your existing IndraControl VPP21.1-BQD-512D-P7D-NNNN multi-touch panel, Wake Industrials technicians have the expertise to solve all your automation needs. To get your line back up and running with no hassle, fill out the quote form or call Wake Industrial at 1‑919‑443‑0207.

IndraControl L20 and L25 Programmable Logic Controllers (CML Series)

While the IndraControl V-series covers the operator interfaces, the IndraControl L series comprises the PLC controllers that handle the logical and motion control tasks in the system. Two notable models in this family are the IndraControl L20 and IndraControl L25, which are part of Rexroth’s CML (Compact Modular Logic) controller hardware series​. These controllers are built for modularity and performance, often paired with the IndraControl panels above to form a complete automation solution. IndraControl L20 & L25 controllers are designed to execute PLC programs, coordinate motion axes, and manage I/O in real time, all within a compact DIN-rail mounted unit. Below are some key technical specifications of IndraControl L20 and L25:

1. Processor and Memory: The IndraControl L20 (CML20) is powered by a 200 MHz STMicroelectronics ST40 32-bit CPU (approx. 192 MHz nominal)​, and comes with 16 MB of application RAM, 64 kB NVRAM, and 128 MB flash memory for program storage​. The IndraControl L25 (CML25) offers a higher performance processor (approximately 400 MHz CPU) and an expanded memory capacity, allowing it to handle more complex automation programs and faster control loops. Both units have an integrated real-time clock and watchdog for reliable operation​. This hardware enables the controllers to perform deterministic logic control and motion coordination for numerous axes and I/O points.
2. I/O Capacity and Expansion: The L20 and L25 are modular controllers intended to work with Rexroth’s Inline I/O system. The CML controllers have onboard I/O; the CML20.1-NP-120-NA-NNNN-NW features 8 digital inputs and 8 digital outputs built-in​ and can be expanded with up to 63 inline I/O modules, supporting a maximum of 256 I/O channels​. This provides a highly scalable platform – you can start with a basic setup and add digital/analog I/O, function modules, or specialty modules as needed for your application. The controllers also support technology and safety expansion modules, meaning advanced functions like additional motion axes, or safe PLC functionality can be integrated by snapping in the appropriate module​. In practice, an L25 like the CML25.1-3N-400-NN-NNC1-NW could control an entire machine’s worth of I/O and motion devices, or even multiple machines in a line, thanks to this expandability.
3. Communication Interfaces: IndraControl L-series PLCs come with several standardized communication ports to interface with other devices and higher-level systems. The L20 & L25 provide at least one Ethernet TCP/IP port for programming, HMI connectivity, or factory network integration and one RS232 serial interface for service or lower-level device communication​. Additionally, these controllers can be fitted with fieldbus master or slave modules: for example, the L20 supports an optional Profibus-DP master/slave module​, and other versions in the CML line can interface with SERCOS, CAN, or Ethernet/IP depending on configuration. The modular design means you can choose the network that best fits your architecture. With these interfaces, IndraControl L20 & L25 easily communicate with IndraControl V panels, servo drives, remote I/O, and SCADA systems, acting as the central brain of the operation.
4. Performance and Motion Control: One standout capability of the IndraControl L controllers is their motion control prowess. The CML series CPUs are powerful enough to coordinate up to 64 motion axes in synchronization​. They support Rexroth’s IndraLogic PLC runtime and can integrate with IndraMotion systems for CNC or motion control tasks​. This means an L25 can execute complex motion sequences in real-time, alongside standard PLC logic, all in one unit. Diagnostics features are also built-in – the controllers support various diagnostics for power status, watchdog, and even internal temperature monitoring to alert if overheating. In short, the L20 & L25 are compact but powerful PLCs that bring high-end motion control to space-constrained applications.

IndraControl L20 and L25 units mount easily on DIN rails and are often used in both centralized and decentralized control topologies​. Their robust design and scalable nature make them a popular choice for machine builders using Bosch Rexroth’s automation platform. Wake Industrial stocks both the indracontrol L20 and indracontrol L25 controllers with unopened surplus and refurbished units ready to ship for immediate replacement needs. If your IndraControl PLC is faulty, Wake Industrial also offer expert repair services – our experienced technicians can repair issues down to the component level, whether it’s a communication fault or a burnt-out output, and restore your controller to full function. Wake Industrial’s comprehensive support for the L20 and L25 means you can avoid expensive downtime and extend the life of your existing automation system without the need for costly reprogramming or redesign.
