VEP30.3CCN-256NN-MAD-128-NN-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911170849
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat VEP30.3CCN-256NN-MAD-128-NN-FW is part of the VEP Embedded Terminals series and is equipped with a Celeron 600 MHz processor and 256 MB of RAM. This device features an 8.4 inch display with a resolution of 800 by 600 pixels, supports 262,144 colors, and includes one Ethernet port, two USB 2.0 ports, and one serial RS232 port. It offers IP65 front protection and IP20 device protection, draws a maximum of 36 W, and has dimensions of 296 mm width by 200 mm height by 75 mm depth.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The VEP30.3CCN-256NN-MAD-128-NN-FW is an embedded operator terminal produced by Bosch Rexroth Indramat within the VEP Embedded Terminals series. The unit combines a touchscreen display with a compact industrial PC so that machine builders can integrate visualization, parameter entry, and diagnostic functions directly at the point of use on a cabinet door or mounting arm. It serves as a human-machine interface in automated cells, packaging lines, and assembly stations.
Its front panel carries an 8.4 in TFT display that renders graphics at 800 × 600 pixels and supports 262144 color shades, giving operators clear status indication without external monitors. A Celeron 600 MHz processor runs the control software, while 256 MB of SDRAM handles runtime variables and 128 MB of flash stores the operating system, recipes, and event logs. Communication with higher-level networks is provided through one RJ45 10/100Base-T Ethernet port, and local peripherals such as barcode scanners or memory sticks attach through two USB 2.0 sockets. A 9-pin RS232 D-Sub connector supports legacy serial devices. The aluminum housing occupies 296 mm in width, 200 mm in height, and 75 mm in depth, allowing installation in shallow enclosures or swing arms.
The electronics draw power from a 24 V DC control circuit and never exceed 36 W, so the terminal can share the same low-voltage supply used by sensors and I/O modules. The front foil, touchscreen, and bezel achieve IP65 protection when correctly gasketed, resisting dust and water jets on production floors. The rear section has an IP20 enclosure that is suited for protected cabinet interiors. This layout keeps the operator-facing surface available at the machine while the connections remain inside the cabinet or support arm.
Frequently Asked Questions about VEP30.3CCN-256NN-MAD-128-NN-FW:
Q: What is the display size of the VEP30.3CCN-256NN-MAD-128-NN-FW terminal?
A: The VEP30.3CCN-256NN-MAD-128-NN-FW terminal features an 8.4-inch display for clear and convenient visualization.
Q: How much flash memory is included in the VEP30.3CCN-256NN-MAD-128-NN-FW?
A: This unit is equipped with 128 MB of flash memory for reliable data storage.
Q: What type of Ethernet connectivity is available on the VEP30.3CCN-256NN-MAD-128-NN-FW?
A: The VEP30.3CCN-256NN-MAD-128-NN-FW provides one Ethernet port with RJ45 connector supporting 10/100Base-T.
Q: What level of front protection does the VEP30.3CCN-256NN-MAD-128-NN-FW provide?
A: This model offers IP65 front protection, making it resistant to dust and water splashes at the front panel.
Q: What voltage supply is required to operate the VEP30.3CCN-256NN-MAD-128-NN-FW?
A: The VEP30.3CCN-256NN-MAD-128-NN-FW operates with a 24 V DC voltage supply for reliable usage in industrial settings.
