T SANMOTION Servo Motors

The SANMOTION T series has a range of DC servomotors made for industrial work that needs to be precise. These motors have rated outputs between 23 W and 500 W and outer diameters between 41 mm and 87.5 mm. With rated torques ranging from 0.137 Nm to 1.76 Nm, continuous stall torques up to 1.90 Nm, and instantaneous maximum torques reaching 12.0 Nm in bigger models, these motors can handle many different jobs. Designed to be versatile, they work at a speed of 3000 min⁻¹, with top speeds going up to 5000 min⁻¹ for some setups, helping in various applications very well. Also, the SANMOTION T series can have different winding choices, mostly 24 V systems, with rated armature voltages from 70 V to 85 V. It operates at currents from 1.2 A to 7.6 A, depending on the model you choose. Some cool features that might be helpful are tachometer generators and high-resolution incremental encoders with 1000 pulses per revolution, which is good for getting feedback on position and speed. The rotor inertia is between 0.34 × 10⁻⁴ kg·m² and 18 × 10⁻⁴ kg·m², and the motor mass differs between 0.37 kg and 4.25 kg. Which gives a balance between power and how easy it is to move. Made to last, the SANMOTION T series operates in places with temperatures from 0°C to 40°C and humidity up to 90%, as long as it is not condensing. The servo amplifiers work with main circuit inputs of DC 140 V and control circuits at DC 24 V.
