The YSM Brushless Servo Motors series is a family of low-inertia servo motors designed for motion applications such as robotics, material handling, X-Y tables, light packaging equipment, medical and laboratory devices, office machinery, and postal sorting systems.
The series is offered in 115 V and 230 V windings and includes three frame sizes with ten models to cover a range of machine requirements. Across the lineup, the motors use high-energy neodymium magnets, a low-inertia rotor design, and a motor-mounted 2,000-line optical encoder with differential line-driver feedback and commutation signals. The motors are built with popular metric mounting dimensions, support speeds up to 4500 rpm, and can be ordered with an internally mounted 24 VDC spring-set, magnetic-release holding brake. Across the series there is continuous torque ranging from approximately 0.2 Nm to 2.5 Nm, peak torque up to 7.1 Nm, and an IP43 package for industrial installation.
