S60301-NA
Wake Industrial LLC is not an authorized distributor of this product.
- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The S60301-NA is a SERVOSTAR 603 servo drive designed for industrial applications, featuring IP20 enclosure protection. Part of Kollmorgen's S600 Servo Drives series, it supports a rated supply voltage range from 3x208V to 480V and operates with a clock frequency of 8 kHz. This drive delivers a rated output current of 3A.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
S60301-NA is a SERVOSTAR 603 with AS option variant from Kollmorgen. This designation confirms the drive’s enhanced safety features that prevent unintended restarts. It can support a rated installed load of 2 kVA and operates at a rated supply voltage of 3 x 230V (50Hz) or 3 x 208V (60Hz) up to 480V (±10%). The rated DC bus link voltage is 290 V to 675 V DC, with a broad voltage window that allows for flexible power distribution for various system configurations. The unit delivers a rated output current of 3 A (rms, ±3%).
Additionally, the module can supply a peak output current of 6 A for roughly 5 seconds. This capability meets transient load demands during startup surges. The output stage clock frequency is 8 kHz, increasing to 16 kHz when VDCmax equals 400V. The overvoltage protection threshold spans from 450 V to 900 V. This safeguard protects internal components against voltage spikes. Motors with larger inductive loads may be supported by the maximum load inductance of 75 mH, while the lowest load inductance is 12 mH. With smaller loads, stability is maintained at this lower limit. Because of its IP20 rating, the S60301-NA's enclosure protection is appropriate for indoor industrial applications.
Protection against dust and other minor environmental conditions is guaranteed by this certification. At rated data, the ambient operating temperature falls between 0C and +45C, with power derating above +45C. Quiescent dissipation is approximately 15 W when the output stage is disabled. This low power loss reduces energy consumption during idle periods. Dissipation at rated current is about 40 W, including power supply losses but excluding brake dissipation. This thermal efficiency supports sustained operation under load. The drive offers 2 analog setpoint inputs (±10V, 14bit/12bit resolution), 4 programmable digital inputs, and 2 programmable digital outputs. This versatile I/O configuration enables precise and flexible control integration.
Frequently Asked Questions about S60301-NA:
Q: What benefit does the overvoltage protection threshold provide in S60301-NA drive?
A: The overvoltage protection threshold of 450 V to 900 V safeguards the drive against damaging voltage spikes. It maintains the integrity of the system during electrical disturbances.
Q: How does the clock frequency of 8 kHz (16 kHz with VDCmax = 400V) improve S60301-NA’s performance?
A: This clock frequency enhances the drive’s dynamic response and control precision. It supports rapid switching for better overall performance.
Q: How does the rated DC bus link voltage of 290 V to 675 V DC benefit S60301-NA?
A: It allows for flexible power distribution across different system configurations. It supports diverse motor and supply arrangements effectively.
Q: What benefit does the rated installed load of 2 kVA offer in S60301-NA?
A: This load value guarantees reliable operation under standard load conditions. It provides steady performance for typical industrial applications.
Q: How does the rated supply voltage in S60301-NA support your system?
A: It supplies power at 3 x 230V (50Hz) or 3 x 208V (60Hz) up to 480V (±10%). It ensures compatibility with a wide range of industrial power networks.
