This drive series tackles a wide power spectrum, stretching from small 0.
55 kW applications up to hefty 2 MW installations. The lineup breaks down into three voltage categories that cover different application needs. The 208-240V models work well for smaller loads from 0.55 kW to 90 kW, while the 380-500V range handles the middle ground from 1.5 kW to 1200 kW. For larger industrial applications, the 525-690V versions cover 2.0 kW to 2000 kW. When multiple drives need to work together using DriveSynch technology, the power capabilities expand significantly. The 380-500V range can reach 4000 kW in parallel configurations, and the 525-690V series stretches to 4500 kW. This makes them suitable for running large motors that would typically require custom high-power drives. The drives come in three basic packaging options. Wall-mounted versions work for most standard installations, while standalone enclosed units are better when floor mounting or outdoor applications are needed. IP00 modules offer flexibility for custom panel building or when specific enclosure requirements come into play. Each drive includes five expansion slots built into the base unit, which saves on external hardware and simplifies wiring. These slots accommodate various I/O boards, fieldbus interfaces, and safety modules without needing separate junction boxes or additional mounting space.
