Product Description:

The HDS02.2-W040N-HA01-01-FW is a drive controller built by Bosch Rexroth Indramat and supplied in the HDS Drive Controllers series. It belongs to the DIAX04 controller family and functions as a power and control module for servo axes in automated machinery. Installed inside a multi-axis rack, the unit processes motion commands, energizes motor windings, and monitors feedback signals so that positioning and velocity loops stay within programmed tolerances on production lines, material-handling cells, or packaging systems. Its control section supports coordinated axis behavior where repeatable speed and position response are required over changing load conditions.

This controller delivers a continuous output of 40 A, allowing it to drive medium-power servo motors. Command and status data are exchanged through a single-channel analog interface, simplifying integration when the host CNC or PLC already issues ±10 V speed or torque references. Thermal energy created by switching devices is removed by a built-in air blower, so no external fan tray is required. The housing meets the IP10 protection category, which guards against accidental contact with live parts but presumes a filtered cabinet environment. Windings and internal wiring conform to insulation class C, which is suitable for the elevated operating temperatures typical of enclosed electronic assemblies.

Site conditions for this version are capped at 1000 m above sea level to maintain dielectric spacing and cooling performance. Full current is available when ambient air remains between +5 to +45 °C; above this range, output must be reduced, though controlled operation can continue up to +55 °C. During logistics or plant shutdowns, the electronics can withstand temperatures from -30 to +85 °C while unpowered. The operating range and the storage range are separate, so high storage temperatures do not indicate full-load operation at those conditions.
