HDS02.2-W040N-HS33-01-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
4 Minutes
52 Seconds
The Bosch Rexroth Indramat HDS02.2-W040N-HS33-01-FW is part of the HDS Drive Controllers series and is designed for use at elevations up to 1000 meters above sea level. This DIAX04 family drive controller features a SERCOS command communication interface and uses a built-in internal air blower for cooling. It has a rated current of 40 Amps and operates within a permissible ambient temperature range of 5 to 45 degrees Celsius.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The HDS02.2-W040N-HS33-01-FW drive controller is produced by Bosch Rexroth Indramat for the HDS Drive Controllers series. As an axis module inside DIAX04 assemblies, it supplies regulated power to servo motors and exchanges motion commands with higher-level PLCs. In industrial automation, the unit coordinates velocity, torque, and position loops so that connected machinery follows programmed profiles accurately. The controller can be used wherever a machine axis must respond predictably to changing load and speed demands.
Command data reach the controller through the SERCOS fiber-optic interface, allowing deterministic communication within the DIAX04 multi-axis rack. The power section delivers a continuous output of 40 A, which matches medium-frame servo motors used on packaging, printing, and handling equipment. Thermal stability is maintained by a built-in air blower, which pulls cabinet air across the heat sink instead of relying on external ducting. Protection against accidental contact is limited to IP 10, so the module must be mounted inside an electrical enclosure. Windings and power semiconductors are insulated to class C, permitting higher internal temperatures without dielectric breakdown.
The controller tolerates installation elevations up to 1000 m above sea level without adjustment to its current rating. During operation, it maintains proper performance within an ambient span of +5 ... +45 °C; above this range, output must be derated. Short-term operation in warmer shops is supported up to +55 °C, provided cooling air remains unobstructed. When spare units are stocked, the electronics withstand warehouse or transit extremes from -30 ... +85 °C. The unit is part of Line 02 and Version 2 within the series.
Frequently Asked Questions about HDS02.2-W040N-HS33-01-FW:
Q: What communication interface does the HDS02.2-W040N-HS33-01-FW support?
A: The HDS02.2-W040N-HS33-01-FW uses SERCOS as its command communication interface for drive control.
Q: What is the rated current of the HDS02.2-W040N-HS33-01-FW controller?
A: This drive controller operates with a rated current of 40 A for efficient drive control.
Q: What cooling method is used in the HDS02.2-W040N-HS33-01-FW drive controller?
A: Cooling is handled by a built-in internal air blower, keeping components at proper operating temperatures.
Q: What is the operational temperature range for the HDS02.2-W040N-HS33-01-FW?
A: The permissible ambient temperature during operation is between +5°C and +45°C for this model.
Q: What protection category does the HDS02.2-W040N-HS33-01-FW offer?
A: The HDS02.2-W040N-HS33-01-FW features an IP 10 protection category according to DIN 40 050 standards.
