Product Description:

The HDS02.1-W040N-HA01-01-FW is a modular drive controller produced by Bosch Rexroth Indramat for the HDS Drive Controllers series. Within automated assembly lines and machining centers, the device supplies regulated power and control signals to matched drive modules so motor motion follows commanded profiles accurately. As a component of the DIAX04 family, it integrates into multi-axis racks, linking upstream CNC or PLC commands to power stages that actuate servo or spindle motors. Its rack-based format supports coordinated control where several axes operate from the same cabinet platform.

The drive is rated for 40 A continuous output current, providing sufficient headroom for medium-power axes without exceeding thermal limits. Control signals enter through an analog command interface, allowing the rack-mounted controller to accept ±10 V velocity or torque references directly from motion processors. That input style suits systems that rely on continuous reference signals rather than networked motion commands. A built-in air blower draws cabinet air across heat-generating components, eliminating the need for external ducting. Electrical safety is addressed by an IP 10 housing and an insulation system qualified to Class C under DIN VDE 0110. The unit belongs to the DIAX04 controller family, Line 02, and it is Version 1.

For field deployment, the controller can be stored or shipped between -30 to +85 °C, and it operates reliably within an ambient range of +5 to +45 °C. If cabinet temperatures rise, operation may be derated but remains permissible up to +55 °C. Proper airflow must also be maintained at elevations of up to 1000 m above sea level to preserve cooling efficiency. The controller is intended for cabinet mounting where air circulation and surrounding temperature directly affect heat removal during operation.
