MSM030C-0300-NN-M0-CC0
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911295574
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
Available
MSM030C-0300-NN-M0-CC0 MSM Servo Motor is manufactured by Bosch Rexroth Indramat. This motor has a Multiturn, Absolute encoder and a Cable Tail electrical connection. This motor comes with a With Key per DIN 6885-1 shaft and is Not Equipped with a holding brake.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSM030C-0300-NN-M0-CC0 is a synchronous servo motor from Bosch Rexroth group in its MSM series. The motor comes with a compact design and features connectors for power and encoder connection. It supports a pollution degree of 2 according to EN 50178 specifications. The device features a range of magnetic materials. Over a prolonged period, the unit may experience fluid entry from the output shaft when it is mounted vertically with the drive side of the flange oriented upward. This can damage the motor in the long run. The device has a winding type of 0300. The motor comes with a warranty period of one year.
The synchronous motor features a cable type electrical connection and a multi-turn absolute encoder. The two-part type plate of the device offers various details such as the part, model and serial numbers, rated voltage, power and current, hardware index, speed, degree of protection, insulation class, and more. The unit must not have icing or moisture condensation during transport. It must be safely and professionally fastened to the machine on which it is installed using DIN912 screws and corresponding washers, if needed. The device does not have protection against hazardous substances such as chlorinated hydrocarbons, asbestos, and mercury.
The motor features a shaft with a shaft key that is designed according to DIN 6885-1 specifications. The unit does not support the use of a holding brake. It has a power rating of 400W. The device is intended for use with the DKCxx.x-012 series of drives from the manufacturer. The thermal connection between the installed machine and the motor gets changed when a gearbox is added to the motor and the torque reduces by 10% to 20%. The unit features an IP 54 protection rating. We can ship the motor to any address worldwide through our trusted global delivery partners.
Frequently Asked Questions about MSM030C-0300-NN-M0-CC0:
Q: What are torque ratings for the motor?
A: The continuous torque at standstill is 1.2 Nm and the maximum torque is 3.8 Nm.
Q: What are typical applications for EcoDrive systems with MSM motors?
A: Typical applications include handling systems, packaging machines, mounting systems, printing machines and machine tools.
Q: What are current ratings for the motor?
A: The continuous current at standstill is 2.3 Amps and the peak current is 7.4 Amps.
Q: What is the recommended size for the motor power cable?
A: The recommended minimum power cable cross section is 0.75 mm2.
Q: What are the protection ratings?
A: Protection rating for the motor housing is IP65. Protection rating for the motor shaft is IP40.
