DDS02.1-A150-DL01-01-FW
MPN: R911266528
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships Today
The DDS02.1-A150-DL01-01-FW Servo Drive is manufactured by Bosch Rexorth Indramat. The drive operates with External Cooling, 150 A rated current, and Digital Servo Feedback.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The Bosch Rexroth DDS02.1-A150-DL01-01-FW is a modular drive controller. The output current rating of the controller is 150 Amps. The permissible ambient temperature with rated data is 0 to 45 degrees Celsius. The maximum permitted ambient temperature with derated data is 55 degrees Celsius. The output of the controller derates to 80% of rated values at 55 degrees Celsius. The temperature range specified by Bosch for storage and transportation of the DDS02.1-A150-DL01-01-FW is -30 to 85 degrees Celsius. The maximum permitted elevation with rated data is 1000 meters above sea level. The controller output derates to 65% at 5000 meters altitude. The maximum permitted operating relative humidity is 95%. The DDS02.1-A150-DL01-01-FW comes in an IP10 rated enclosure that is designed for panel mounting. The unit is not protected against water penetration or intentional accessing by hand.
Weight of the controller is approximately 11 kilograms. DC bus voltage on the DDS02.1-A150-DL01-01-FW is 300 Volts which can vary up to ±15%. The controller has the advantage that most of the energy dissipated by the unit is directly conducted outside the bus and does not accumulate inside the control cabinet. The controller can be mounted inside compact control cabinets without requiring extensive heat conductance or costly heat-exchanging unit. The electrical section of the blower is protected within the control cabinet. The DDS02.1-A150-DL01-01-FW controller supports digital servo feedback. The communication module shipped with the controller is single axis position control. The product firmware needs to be added as a separate subposition. Only trained and qualified technical personnel should handle and install the DDS02.1-A150-DL01-01-FW controller. Safety instructions listed in the product documentation should be implemented to prevent injury and equipment damage.
Frequently Asked Questions about DDS02.1-A150-DL01-01-FW:
Q: What are the key features of the Bosch Rexroth DDS02.1-A150-DL01-01-FW?
A: The Bosch Rexroth DDS02.1-A150-DL01-01-FW is a modular drive controller designed for panel mounting, featuring an IP10 rated enclosure. It is not water-resistant or protected against intentional hand access, ensuring its use in secure and controlled environments.
Q: How does the output of the DDS02.1-A150-DL01-01-FW change with temperature?
A: The output of the DDS02.1-A150-DL01-01-FW derates to 80% of its rated values at temperatures reaching 55 degrees Celsius. This derating ensures the controller's longevity and consistent performance under varying thermal conditions.
Q: What advantages does the DDS02.1-A150-DL01-01-FW offer in terms of energy dissipation?
A: The DDS02.1-A150-DL01-01-FW efficiently conducts most of the energy it dissipates directly outside the bus, preventing heat accumulation inside the control cabinet. This feature makes it ideal for compact control cabinets without the need for extensive heat conductance solutions.
Q: Is the electrical section of the DDS02.1-A150-DL01-01-FW's blower protected?
A: Yes, the electrical section of the blower in the DDS02.1-A150-DL01-01-FW is protected within the control cabinet. This protection is crucial for maintaining the integrity and safety of the electrical components, especially in industrial settings where exposure to harsh conditions is common.
Q: Does the DDS02.1-A150-DL01-01-FW support digital servo feedback and how is its firmware managed?
A: The DDS02.1-A150-DL01-01-FW supports digital servo feedback, providing precise and efficient control for various applications. However, the product firmware needs to be added as a separate subposition, allowing for tailored and upgradable software solutions to meet specific operational requirements.
