The TBM Frameless Motors series is a family of frameless motors offered in multiple diameters and stack lengths, including approximately 59 mm, 75 mm, and 129 mm platforms.
And has bore sizes from 28.7 mm to 55.88 mm. The series includes different winding and voltage versions, with 24 VDC, 48 VDC, and 100 VDC models listed so the motors can be matched to different bus voltages and performance requirements. Across the provided models, continuous stall torque ranges from about 0.39 N·m to 10.4 N·m, peak stall torque reaches as high as 36.2 N·m, and maximum speed extends to 5600 rpm depending on frame size and winding selection. The mechanical design is intended for integration into the host machine, with the rotor supported by machine bearings rather than an internal bearing set in the motor assembly. Depending on the model family, the series offers hall-effect feedback availability or no integrated feedback.
