The MKD041B-144-GG1-KN servo motor is a part of the MKD Servo Motor Series manufactured by Bosch Rexroth. This motor's winding code is 144, it incorporates Resolver feedback , operates with a Plain Shaft and is Equipped with a holding brake.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

MKD041B-144-GG1-KN

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911261578
  • Stock: In-Stock, Ships 3-5 Days
  • Call for Expedited Shipping and Product Condition Options
The MKD041B-144-GG1-KN servo motor is a part of the MKD Servo Motor Series manufactured by Bosch Rexroth. This motor's winding code is 144, it incorporates Resolver feedback , operates with a Plain Shaft and is Equipped with a holding brake.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a MKD041B-144-GG1-KN to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Bosch Rexroth is a well-equipped engineering firm with highly trained and skilled engineers who thrive in manufacturing powerful and resilient automation components such as the drive controllers, synchronous motors, inverter units, and specially designed power cables. With integrated and dynamic systems, these components accommodate many appliances and can function efficiently in innumerable fields. Here, we focus on the technical information of the MKD041B-144-GG1-KN motor.

The rated data of the MKD041B-144-GG1-KN motor matter and apply only in natural cooling method. The rated voltage ranges from 115V to 170 V and a frequency of 150Hz – 225Hz. The rated torque is 1.4 to 1.5Nm and the rated speed is 3000 Nm to 4500 Nm. MKD041B-144-GG1-KN operates at a rated power of 0.52 to 0.88 KW and a rated current of 2.8 -3.0 A. The mechanical parameters of the MKD041B-144-GG1-KN play a key role especially in storage, installation, and transport. In both surface and natural cooling, the theoretical maximum torque is 11.3Nm and an estimated rotor inertia value of 1.7 x 10-4 kgm². When cooling the motor naturally, the thermal time constant is 30 minutes, an estimated speed of 7500 min-1, and a minimum cross-section of the strand value of 1 mm2.

The MKD041B-144-GG1-KN has a mass value of 4.4kg and should be transported and stored at a temperature of -20 to +80°C. The highest set up should be 1000 meters above NN and the permissible ambient temperature is 0°C to 40°C. If you exceed the suggested mounting height, then you must reduce the performance data accordingly. The motor has an insulation class of F according to the DIN VDE 0530 Part 1 and a protection category of IP65 as long as the encoder and power cables are properly installed.





MKD041B-144-GG1-KN Documents

  • MKD041B144GG1KN
  • MKD041B 144 GG1 KN
  • mkd041b-144-gg1-kn

MKD041B-144-GG1-KN Technical Specifications

Driven Shaft: Plain Shaft
Holding Brake: Equipped
Motor Feedback: Resolver feedback
Windings Code: 144
