HDS03.2-W075N-HS12-01-FW
MPN: R911190008
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships Today
The HDS03.2-W075N-HS12-01-FW drive controller delivers reliable motion control with a rated input voltage of 530-670 V. It features short-circuit protection up to 42,000 A and operates efficiently in temperatures up to 55 degrees C.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
Bosch Rexroth Indramat is known for producing high-performance motion control systems. The company product line includes drive controllers, servo motors, frequency converters, linear motors and industrial automation components designed for industries requiring precise and reliable control systems.
The HDS03.2-W075N-HS12-01-FW drive controller is engineered to provide reliable motion control for industrial applications. It operates with a rated control voltage input of 26 V ~ 2% and supports continuous input currents of up to 37 A. Its UL certification (UL 508C) and use in pollution degree 2 environments make it suitable for use in controlled, clean environments. The device is equipped with robust short-circuit protection (SCCR) up to 42,000 A and operates efficiently at ambient temperatures of up to 45 degrees C, extendable to 55 degrees C under reduced load conditions. With dimensions of 498 mm height, 308 mm depth, and 100 mm width, it provides compact and efficient integration options. The rated input voltage range of 530 - 670 V ensures that it supports a wide range of power systems in industrial environments.
The HDS03.2-W075N-HS12-01-FW drive controller has a maximum output current of 40 A and an operational frequency limit of 1000 Hz that enables high-speed performance. The HDS series drive controller is designed for a three-phase output with a maximum output voltage of 500 V. For connectivity, the controller employs a screw-type terminal with a four-pin socket for ease of installation. Its recommended wiring includes 60/75 degrees C copper wire, and it supports wire cross-sections of up to 35 mm^2. The recommended torque for the motor and DC bus connections ranges between 3 Nm and 6 Nm, depending on the model configuration. This drive controller is also equipped with advanced thermal management and ensures optimal performance under heavy loads with continuous power dissipation of up to 220 W.
Frequently Asked Questions about HDS03.2-W075N-HS12-01-FW:
Q: What is the connectivity option in the Bosch Rexroth HDS03.2-W075N-HS12-01-FW drive controller?
A: The drive controller uses a screw-type terminal with a four-pin socket. This makes installation easier and more reliable. It supports wire cross-sections of up to 35 mm^2 for proper connectivity.
Q: What is the maximum output current and frequency limit of the HDS03.2-W075N-HS12-01-FW drive controller?
A: The controller supports a maximum output current of 40 A. It operates with a high-speed frequency limit of 1000 Hz, ensuring efficient performance for demanding industrial applications.
Q: What are the environmental operating conditions for the HDS03.2-W075N-HS12-01-FW drive controller?
A: The drive controller operates efficiently at ambient temperatures of up to 45 degrees C. It can be extended to 55 degrees C under reduced load conditions. It is UL certified and suited for pollution degree 2 environments.
Q: What is the input voltage range for the Bosch Rexroth HDS03.2-W075N-HS12-01-FW drive controller?
A: The rated input voltage range is 530 to 670 V. This wide range allows the controller to support various power systems in industrial environments, ensuring versatility and reliability.
Q: What type of protection does the HDS03.2-W075N-HS12-01-FW drive controller offer?
A: The drive controller is equipped with short-circuit protection (SCCR) up to 42,000 A. This robust protection ensures safety during operation and protects the system from electrical faults.
