SC935TN-034-01

  • Rated 4.4 (27 total ratings)
  • Stock: In-Stock, Ships in 3 Days
  • Call for Expedited Shipping and Product Condition Options
SC900 Series Servo Drive manufactured by Pacific Scientific. This Servo Drive features a Power Level of 30 A cont. @ 50 degrees C, 60.0 A pk. along with a Base Servo Software Type of Customization Code.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock!

SC935TN-034-01

  • Rated 4.4 (27 total ratings)
  • Stock: In-Stock, Ships in 3 Days
  • Call for Expedited Shipping and Product Condition Options
SC900 Series Servo Drive manufactured by Pacific Scientific. This Servo Drive features a Power Level of 30 A cont. @ 50 degrees C, 60.0 A pk. along with a Base Servo Software Type of Customization Code.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a SC935TN-034-01 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The SC935TN-034-01 is well known among SC900 series by Pacific Scientific. The serial communications option card for your Pacific Scientific’s SC935TN-034-01 is used to communicate more than a 9600 Baud serial link to host your personal computer. A menu-driven software support package runs on your PC Combined with 930 Dialogue. The SC935TN-034-01 offers the following features:

  • All-digital setup of the velocity loop, current loop, and position loop. There are no pots, plug-on jumpers, DIP switches, or components to change when setting up the servo loops. The parameters are downloaded using an RS-232 or RS-485 port and are saved in nonvolatile memory in the SC935TN-034-01.
  • Simplified uploading, downloading, and disk storage of the SC935TN-034-01 parameters for easy cloning and backup documentation.
  • Automatic drive setup using 930 Dialogue.
  • Automatic Analog Command Offset adjustment using 930 Dialogue.
  • Accurate readout of position, motor velocity, and other variables using the serial link and 930 Dialogue

The SC935TN-034-01 firmware controls the base SC900 drive, whether the OC930 Serial Option Card is installed or not. The SC935TN-034-01 is configured as a serial port commanded controller. The current loop is compensated properly for the selected motor and the servo parameters are setup to give medium response (approximately 75 Hz velocity loop bandwidth) with the unloaded motor. Additional default settings were also made.

The SC935TN-034-01 compiles with EC Directives. The Pacific Scientific’s SC935TN-034-01 has a two-year warranty against defects in material and assembly. The warranty is exempt in the following cases: If the products that have been modified by the customer, physically mishandled, or otherwise abused through mis-wiring, and so on. Follow the rules and regulations given by manufacturer to ensure safety.

  • SC935-TN-034-01
  • SC935TN 034 01
  • SC935TN-O34-O1
  • SC935TN03401

SC935TN-034-01 Technical Specifications

Servo Drive Family: SC9
Command Interface Option Card Designation: OC930-001-00 installed, RS-232/485 Serial Communications/Setup Analog, Incremental Digital, or Serial Command
Power Level: 30 A cont. @ 50 degrees C, 60.0 A pk.
Accessories and Cooling Options: TB adapter connector kit, manual(s) / No fan, convection cooled
Customization Code: Base Servo Software Type
