P22NRXA-LDF-M1-00

  • Rated 4.6 (9 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Call for Expedited Shipping and Product Condition Options

The P22NRXA-LDF-M1-00 is manufactured by Pacific Scientific as part of the Powermax II P stepper motor series. It features a thermal resistance of 4.5 Mounted °C/Watt and rotor intertia of 0.025(kg-m²x10¯³). These are the most powerful stepper motors with a holding torque of 1.68 Nm and a detent torque of .12 Nm.

Wake Industrial LLC is not an authorized distributor of this product.

P22NRXA-LDF-M1-00

  • Rated 4.6 (9 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Call for Expedited Shipping and Product Condition Options

The P22NRXA-LDF-M1-00 is manufactured by Pacific Scientific as part of the Powermax II P stepper motor series. It features a thermal resistance of 4.5 Mounted °C/Watt and rotor intertia of 0.025(kg-m²x10¯³). These are the most powerful stepper motors with a holding torque of 1.68 Nm and a detent torque of .12 Nm.

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

The P22NRXA-LDF-M1-00 is one of the several POWERMAX II brand hybrid stepper motors. This P series motor from Pacific Scientific has a size of 2.25 inches across flats and two stacks on the rotor. The bearings have a size of 30mm that makes them bigger than the bearings usually found in devices of the same size. The device has an inertia of 0.022kgm3 x 10-3. The unit renders a dependable and high-quality operation. The extra size of the bearings helps in increasing their fatigue life. The product is characterized by dependable and high-quality operation because of the polymer encapsulation surrounding the stator. The motor is backed by a one-year warranty period.

The stepper motor uses an end bell to run the cooler and improve the lifetime of the encoder. The device can be mounted using the NEMA type mounting option through four mounting holes. It features an all-in-one molded stator assembly and NEMA Class B insulation at 130°C. The large-size 30mm bearings of the product help in extending the lifespan of the motor. The product comes fitted with the provision to mount an encoder for feedback. The unit supports receptacle type termination and the mating leaded connectors are available separately. The motor can be shipped to any address worldwide through our logistics agents.

The hybrid motor is fitted with a double-ended shaft that has a flat-style modification. It has a diameter of 0.375 inches that is bigger than the shafts of the usual NEMA 23 motors. The device has an angular accuracy of 1.8°. The unit offers the assurance of high-speed efficiency because of its laminated rotor. The standard winding of A makes the motor ideal for any application. The stepper motor operates between an ambient temperature range of -20°C and +40°C.

  • P22 NRXA LDF M1 00
  • P22-NRXA-LDF-M1-00
  • P22NRXA LDF M1 00
  • P22NRXA-LDF-M1-OO
  • P22NRXALDFM100
  • P22NRXALDFM1OO

P22NRXA-LDF-M1-00 Technical Specifications

Axial Force: 58N
Radial Force: 89N
Weight: 1.13 kg
Type: Standard
Thermal Resistance: 4.5 Mounted °C/Watt
Rotor Inertia: 0.025(kg-m²x10¯³)
Holding Torque: 1.68 Nm
Detent Torque: .12 Nm
Encoder Option/Sequence Number: Encoder mounting provisions/Standard
Size: NEMA 23
Number of Stacks: 2 Stacks
Mounting: NEMA
Construction: Regular
Termination: Receptacle
Winding Type: per assigned letter
Rotor Type: Standard
Shaft Configuration/Shaft Modifications: Double/Flat
