P21NRXD-LNN-NS-00

  • Rated 4.7 (18 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
    In-Stock, Ships in 3 Days
  • Call for Expedited Shipping and Product Condition Options

The P21NRXD-LNN-NS-00 is manufactured by Pacific Scientific as part of the Powermax II P stepper motor series. It features a thermal resistance of 5.5 Mounted °C/Watt and rotor intertia of .012 (kg-m²x10¯³). These are the most powerful stepper motors with a holding torque of .82 Nm and a detent torque of .028 Nm.

✓ In-Stock!

Wake Industrial LLC is not an authorized distributor of this product.

P21NRXD-LNN-NS-00

  • Rated 4.7 (18 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
    In-Stock, Ships in 3 Days
  • Call for Expedited Shipping and Product Condition Options

The P21NRXD-LNN-NS-00 is manufactured by Pacific Scientific as part of the Powermax II P stepper motor series. It features a thermal resistance of 5.5 Mounted °C/Watt and rotor intertia of .012 (kg-m²x10¯³). These are the most powerful stepper motors with a holding torque of .82 Nm and a detent torque of .028 Nm.

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

Pacific Scientific remains the world’s leading supplier of motion control technology. With quality as an important component in its manufacturing, the company provides outstanding solutions and services that are unmatched. Pacific Scientific provides excellent quality products as well as reliable delivery.  The invention of the P21NRXD-LNN-NS-00 motors has brought about outstanding cost and performance value in the hybrid set motors. The P21NRXD-LNN-NS-00 motors provide higher torque and speed range.

The P21NRXD-LNN-NS-00 motors are connected in a series arrangement having a holding torque ranging from 109 to 0.77 Nm with a rated current of 1.51 A.  Its phase resistance is 2.61 Ω while its phase inductance stands at 10.3 mH. The P21NRXD-LNN-NS-00 motors’ net weight range as 1.5 to 0.68 kg. The motors have a double rotor stack. The rotor stack is categorized as the standard inertia and the low inertia rotors. The low inertia rotor produces higher acceleration rates possible.

The low inertia rotor ranges between 2.59 to 0.016 Kg 2 X 10-3 while the standard rotor inertia range between 3.57 and 0.022 Kg 2 X 10 -3. The motor's thermal resistance is 5.5 0 C /watt and its detent torque ranges from 4 to 0.028 Nm.  When the rated current is applied the winding is at 130 0 C and the motor unmounted in still air at 40 0 C without a heat sink.  The thermal resistance of the P21NRXD-LNN-NS-00 motors is measured with the motor hanging unmounted. The motor’s small signal inductance is measured with impedance bridge at 1 kHz, 1 A. Any operation of the P21NRXD-LNN-NS-00 motors that is above the rated current may result in the demagnetization of the motors. You may talk to us to assist you in fixing this.

  • P21 NRXD LNN NS 00
  • P21-NRXD-LNN-NS-00
  • P21NRXD LNN NS 00
  • P21NRXD-LNN-NS-OO
  • P21NRXDLNNNS00
  • P21NRXDLNNNSOO

P21NRXD-LNN-NS-00 Technical Specifications

Axial Force: 58N
Full steps per revolution: 200
Detent torque: 0.028 Nm
Number of Stacks: 1 Stack
Mounting: NEMA
Construction: Regular
Termination: Receptacle
Winding Type: D
Weight: 0.68 kg
Shaft Configuration: Single

Frequently Asked Questions about P21NRXD-LNN-NS-00


Q: What are the holding torque ratings?

A: The holding torque is 0.77 Nm for series and parallel connections and 0.54 Nm for unipolar connections.

Q: What are the current ratings?

A: The current rating is 1.51 Amps for parallel connections, 0.76 Amps for series connections, and 1.07 Amps for unipolar connections.

Q: What is the operating temperature?

A: The recommended operating temperature is from -20 to 40 degrees Celsius.

Q: What are the shaft load ratings?

A: The maximum radial load is 20 pounds and the maximum axial load is 13 pounds.

Q: What is the rated bearing life?

A: The life of 30 mm bearings exceeds 10,000 hours when the motor is operated within peak axial and radial loads.

Internal Product Review

  • ‘‘P21NRXD-LNN-NS-00 is a stepper motor with oversized bearings for long-term reliability.’’
