The MSK101D-0300-NN-M1-AG2-NNNN is manufactured by Rexroth Indramat Bosch as part of the MSK Servo Motor Series. It features a continuous torque of 57.0 Nm and a continuous current of 26.8 A. It also displays a maximum torque of 160.0 Nmand a maximum current of 137.7 A and a winding inductive of 3,200 mH

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock!

MSK101D-0300-NN-M1-AG2-NNNN

  • Rated 4.2 (12 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911310895
  • Stock: In-Stock, Ships Fast
  • Factory New Pricing Available!
    Request a Quote!
  • Call for Expedited Shipping and Product Condition Options
The MSK101D-0300-NN-M1-AG2-NNNN is manufactured by Rexroth Indramat Bosch as part of the MSK Servo Motor Series. It features a continuous torque of 57.0 Nm and a continuous current of 26.8 A. It also displays a maximum torque of 160.0 Nmand a maximum current of 137.7 A and a winding inductive of 3,200 mH

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a MSK101D-0300-NN-M1-AG2-NNNN to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The MSK101D-0300-NN-M1-AG2-NNNN is a Synchronous Motor produced by Bosch Rexroth Indramat in the MSK series. This series has a group of devices that have the characteristic outstanding output and wide usage of power applications. These motors come with minute differences in features that give them specific usability. The MSK 101 group especially displays the Continuous standstill values of torque as Nm 50.0 Nm and current as 30.6 Amps at 60 K, while the maximum values are 160 Nm and 137.7 Amps, respectively.

The built quality of the MSK101D-0300-NN-M1-AG2-NNNN synchronous motor displays some outstanding features. These motors are constructed upon the frame of size -101 with the length type D. The core carries the highest grade of lamination that gives it a high level of safety with the 0300class windings. The overall design of its components and housing is done using a lightweight superior grade of alloys that support natural convection method to diffuse the heat generated during high speeds. Further, the design of its shaft is standard factory fitted with sealing rings at housing outlets and high performance, 70 Nm electrically operated holding brake. The electrical connector on its housing is fixed on its side A. The maximum length for encoder and power line cables is up to 75 meters. There is an optical encoder of the Hiperface, multiturn type with Absolute (having greater than 4096 revolutions) with the accuracy of ± 80 angular seconds.

IndraDyn S motors are designed to be used in combination with the IndraDrive drives. Their compact and robust designs along with the several possible configurations the MSK motors give the users many possible options to choose from as per their specific demands.

  • MSK-101D-0300-NN-M1-AG2-NNNN
  • MSK101D 0300 NN M1 AG2 NNNN
  • MSK101D0300NNM1AG2NNNN

MSK101D-0300-NN-M1-AG2-NNNN Technical Specifications

Product : MSK motor
Max speed: 4600 RPM
Cooling: Natural convection
Max ambient temperature: 40 °C
Continuous Current: 30.6 Amps
Holding brake: 70 Nm
Motor design: Standard
Shaft : Plain
Weight: 46.2 kg
Sound pressure: < 75 dB

Frequently Asked Questions about MSK101D-0300-NN-M1-AG2-NNNN


Q: What are MSK motor applications?

A: MSK motor applications include machine tools, printing and paper-processing machines, packaging and food-processing machines, metal-forming machines and robotics.

Q: What types of encoders do MSK motors support?

A: MSK motors support three types of multiturn encoders and three types of singleturn encoders.

Q: Do MSK motors support holding brakes?

A: Holding brakes are avaiable as an option for MSK motors. Operators must specify the required holding brake at the time of ordering.

Q: What is the benefit of a shaft seal?

A: A shaft seal prevents dust and moisture ingress, and is specially useful when the motor is installed with the shaft pointing vertically upwards.

Q: What is the benefit of an IP65 rated housing?

A: An IP65 rated housing allows motor operation in multiple environments, as the motor is dustproof and protected from low-pressue water jets.

Internal Product Review

  • ‘‘MSK101D-0300-NN-M1-AG2-NNNN is a Bosch Rexroth industrial motor designed for precision control applications.’’
