Product Description

The KDV 1.2-100-220-300-115 power supply unit features a version code of 2 and a series code of 1. The module is used with AC servo drives from the same manufacturer Bosch Rexroth. It has a nominal voltage rating of 220VAC. The product is fitted with an overload warning sensor. The device is capable of offering consistent performance while rendering correct and uninterrupted power to a control system at the same time. The servo drive used with the module helps in the transformation of the AC voltage into DC bus power.

This product features a 100A current rating. The servo drive utilizing the module is installed inside a control cabinet or a closed housing and is used for CNC machine tools. The servo drive along with a servomotor, a servo controller and a feedback device forms a complete servo system. The feedback device used is generally an encoder. The power supply helps in transforming the electric current from an external source to the accurate voltage, frequency and current for powering a load. The product features a compact and robust design. The heatsink can be removed if the power supply has no chances of getting overheated during operation.

The device has nominal voltage ratings of 300VDC for the DC bus and 115VAC for the heatsink blower. The unit is equipped with LEDs for indicating the power ON/OFF status and the earth connection. Its operational checkup and maintenance can be done quickly because of the conveniently positioned control or blower voltage fuses and heatsink blower connections. The DC bus power produced is directed to the servo drive. The module can also work along with converters, inverters and other power supplies. The power supply unit can be transported to any address in the world with a warranty for one year.
