HDS04.2-W200N-HS56-01-FW
- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships 3-5 Days
The HDS04.2-W200N-HS56-01-FW drive controller supports a continuous input current of up to 60 A and a rated power consumption of 30 W. It also features a 500 V maximum output voltage.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
Bosch Rexroth Indramat is known for its motion control systems and industrial automation technologies. Its extensive product range includes servo drives, controllers, servo motors, linear motors, amplifier cards and hydraulic systems. The company is widely recognized for producing high-quality industrial automation equipment.
The HDS04.2-W200N-HS56-01-FW drive controller is designed for high-performance applications and offers a pollution degree 2 rating. It operates at a maximum ambient temperature of 45 degrees C with nominal data, which can increase to 55 degrees C when operating under reduced nominal data. The drive dimensions are 498 mm in height, 308 mm in depth, and a width range of 150 mm. It weighs approximately 19 kg and requires a minimum clearance of 300 mm above and 100 mm below for proper ventilation. The rated control voltage input is 26 V ~ 2 % and the rated power consumption without braking is 30 W. The unit features a short-circuit current rating of 42,000 A, and the rated input voltage range is 530 - 670 V. The continuous input current varies with load conditions, peaking at 60 A. The maximum output voltage is 500 V, and it operates at a frequency of 1,000 Hz. The model must be used with the accessories mentioned by the manufacturer.
For electrical connections, the HDS04.2-W200N-HS56-01-FW drive controller uses a screw-type terminal with a 4-pin design. The recommended wire cross-section for single-core wires is between 2.5-16 mm^2, while for multi-core wires, it ranges from 2.5-35 mm^2. For torque specifications, the DC bus requires 3 Nm, and motor connections are tightened at 4 Nm. The device's maximum output current is rated at 120 A with a continuous power dissipation rating of 800 W. This ensures effective and reliable performance in demanding industrial environments.
Frequently Asked Questions about HDS04.2-W200N-HS56-01-FW:
Q: What are the electrical connectivity options for the HDS04.2-W200N-HS56-01-FW drive controller?
A: The HDS04.2-W200N-HS56-01-FW drive controller features a screw-type terminal with a 4-pin design. It supports a wire cross-section range of 2.5-16 mm^2 for single-core and 2.5-35 mm^2 for multi-core wires.
Q: What is the maximum ambient temperature the HDS04.2-W200N-HS56-01-FW can operate at?
A: The drive controller can operate at a maximum ambient temperature of 45 degrees C with nominal data. This can increase to 55 degrees C when operating under reduced nominal data conditions.
Q: What is the maximum output current and power dissipation rating of the HDS04.2-W200N-HS56-01-FW?
A: The drive controller has a maximum output current rating of 120 A. It also offers a continuous power dissipation rating of 800 W, ensuring reliability in demanding applications.
Q: What are the torque specifications for the DC bus and motor connections on the HDS04.2-W200N-HS56-01-FW?
A: The DC bus connections on the HDS04.2-W200N-HS56-01-FW require 3 Nm torque. The motor connections need to be tightened at 4 Nm for optimal performance and safety.
Q: What are the environmental and installation requirements for the HDS04.2-W200N-HS56-01-FW?
A: The drive controller requires a pollution degree 2 environment and a minimum clearance of 300 mm above and 100 mm below for proper ventilation. This ensures safe and efficient operation.
