HDD02.2-W040N-HA01-01-FW

  • Rated 4.7 (29 total ratings)
  • Stock: Available
  • Call for Expedited Shipping and Product Condition Options
The HDD02.2-W040N-HA01-01-FW Servo Controller is manufactured by Rexroth Indramat Bosch. This controller has an Internal Air Cooling and a rated current of 40. The Controller Family is DIAX04 and a Command Communication of SERCOS.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

HDD02.2-W040N-HA01-01-FW

  • Rated 4.7 (29 total ratings)
  • Stock: Available
  • Call for Expedited Shipping and Product Condition Options
The HDD02.2-W040N-HA01-01-FW Servo Controller is manufactured by Rexroth Indramat Bosch. This controller has an Internal Air Cooling and a rated current of 40. The Controller Family is DIAX04 and a Command Communication of SERCOS.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a HDD02.2-W040N-HA01-01-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The HDD02.2-W040N-HA01-01-FW drive controller is one of the several such controllers in the HDD product group. This controller from Bosch Rexroth makes use of a factory assigned option for command communication. The product has a current rating of 40A. It can be used to activate two motors and supports a fixed configuration. The device must be put to use outside the specified operating range only when load factors are considered. The unit features a modular concept and acts as a rapid-response drive. The controller may require an HZB brake resistor for controlling the generated energy due to braking when the drive performance is very high.

The drive controller might incorporate an HZK capacitor module when there are a large number of start-stop cycles. The device can be used in robotics, machine tools, printing and packaging machinery, handling, and textile machines. The unit has a function ID code of 01. It uses a built-in blower for air circulation. The motor power cable used to connect the product to the appropriate motor has a maximum length of 75m. Connection wires must be used to connect multiple controllers adjacent to each other. The product must operate between 5°C and 45°C. It can be sent to your address with a one-year warranty.

The controller must be operated within a maximum elevation of 1000m above sea level without lowering the rated data. The device has a Class C insulation according to DIN VDE 0110 specifications. It comes with two types of plates. One is located at the top and gives details of the basic unit. The other one is present in the front of the unit. The product must be mounted vertically using mounting rails. The motor connection must be done at the bottom. The maximum operating temperature cannot exceed 55°C with derated data while the storage and transport temperature ranges between -30°C and 85°C.

  • HDD022W040NHA0101FW
  • HDD02 2 W040N HA01 01 FW
  • hdd02.2-w040n-ha01-01-fw

HDD02.2-W040N-HA01-01-FW Technical Specifications

Command Communication: SERCOS
Controller Family: DIAX04
Cooling: Internal Air
Rated Current: 40
