DKS01.1-W030B-DL01-01-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911266496
The Bosch Rexroth Indramat DKS01.1-W030B-DL01-01-FW is a digital servo drive from the DKS Intelligent Digital Servo Drives series. It features a rated current of 30 Amps and supports an input voltage of 230 V AC for both single-phase and three-phase configurations. The drive uses a DSF resolver encoder type and has a bleeder continuous power rating of 0.3 kW.
Internal Product Review
The DKS01.1-W030B-DL01-01-FW is a Bosch Rexroth Indramat digital servo drive configured for MDD motor control with a 30 A rated current. Heat-dissipation cooling and an 18 kHz PWM frequency support stable thermal behavior and smooth drive response in demanding motion applications. Reduced noise emission makes the unit a strong choice for efficient servo performance.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DKS01.1-W030B-DL01-01-FW belongs to the DKS Intelligent Digital Servo Drives series manufactured by Bosch Rexroth Indramat. As a digital servo drive, it works with MDD motors to supply regulated current and position feedback for automated axes in packaging lines, material-handling systems, and similar equipment. Its integrated DSF resolver interface closes the speed loop directly inside the controller, while an internal bleeder circuit dissipates regenerated energy that appears on the common DC bus. This arrangement allows the drive to process motor feedback and power conversion within the same unit for coordinated axis control.
The power section accepts a single-phase input of 230 V AC ±10% or a three-phase 3 × 230 V AC supply with the same tolerance, and it delivers a continuous output of 30 A to the connected motor. A front-end rectifier charges the intermediate circuit to 300 V DC, and a pulse-width-modulated inverter switching at 18 kHz helps provide smooth torque with low ripple. The bleeder can absorb surges up to 5 kW during fast deceleration, and its continuous capacity is 0.3 kW. Under single-phase supply, the unit draws a maximum of 4.5 kVA and releases 230 W of heat loss at full load, which helps keep cabinet temperatures manageable when standard heat dissipation methods are used. The switching stage supports responsive speed and torque control during acceleration, reversing, and positioning moves.
The drive can be installed at elevations up to 1000 m without derating, and the ambient operating temperature can reach 45 °C before current reduction is required. Storage temperature may reach 85 °C, so the unit can be kept in non-climate-controlled warehouses when it is not in operation. A protection class of IP10 limits the drive to clean electrical enclosures, and dedicated heat-sink channels support thermal dissipation during operation. Because of this enclosure class, the unit is intended for installation inside a protected control cabinet rather than on exposed machine surfaces. The resolver feedback also helps maintain position integrity at low speed, even when motor cogging is present.
