SN32HCYR-LNK-NS-01

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • Call for Expedited Shipping and Product Condition Options
SN Series servomotor manufactured by Pacific Scientific. This servomotor features a Mounting Configuration type of Heavy duty NEMA along with a NEMA 34 frame size; 3.38 width/height, square frame Size.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

SN32HCYR-LNK-NS-01

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • Call for Expedited Shipping and Product Condition Options
SN Series servomotor manufactured by Pacific Scientific. This servomotor features a Mounting Configuration type of Heavy duty NEMA along with a NEMA 34 frame size; 3.38 width/height, square frame Size.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a SN32HCYR-LNK-NS-01 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

To seek high precision and accuracy, robotics and motion control engineers and designers always look for lightweight components. Pacific Scientific fulfills there needs by providing hi-tech yet lightweight motors. With PowerSync product line of lightweight AC driven stepper motors, Pacific Scientific creates another opportunity for robotics industry to enhance their features and functionality.

Model number SN32HCYR-LNK-NS-01 refers to smart and lightweight stepper motor that delivers smooth, low-speed performance. The SN32HCYR-LNK-NS-01 stepper motor by Pacific Scientific features rated torque of 4.24 Nm while its rated inertia is 0.52 oz-in-s2. As far as the rotor inertia is concerned, the AC stepper motor offers 0.038 oz-in-s2 rotor inertia. This is the reason why this AC synchronous motor complies with NEMA 34 standards as there is allowance for a larger stator and rotor that account for 30% higher torque. The 8.4-pound SN32HCYR-LNK-NS-01 AC synchronous motor features a powerful winding that offers thermal resistance of 2 degree Celsius per watt. At the same time, it maintains a phase resistance of 53 ohms. The 1SN32HCYR-LNK-NS-01 AC motor by Pacific Scientific offers 60 RPM speed and 50 Hz frequency at just 120 V ac input voltage. Since resistor and capacitor are not included in the package, the manufacturer recommends standard a 50-watt resistor of 100 ohms and a 4 microfarad capacitor of 4.75 Vac rating, to eliminate the risk of reversing torque.

Along with the frame size of 3.38” x 3.38” square frame, the 120 Vac stepper motor by Pacific Scientific also features heavy duty mounting configuration. The MS connector is available at the top for strong connection and three lead winding for trouble-free signal transfer. The SN32HCYR-LNK-NS-01 synchronous motor offers single shaft with straight key, then there is a shaft seal for added protection.

  • SN32 HCYR LNK NS 01
  • SN32-HCYR-LNK-NS-01
  • SN32HCYR LNK NS 01
  • SN32HCYR-LNK-NS-O1
  • SN32HCYRLNKNS01

SN32HCYR-LNK-NS-01 Technical Specifications

Basic Series: SN
Encoder Option/Special Sequence: No feedback/Standard motor with shaft seal
Size: NEMA 34 frame size; 3.38 width/height, square frame
Number of Rotor Stacks: 2 Stacks
Mounting Configuration: Heavy duty NEMA
Construction/Hookup: System MS connector
Winding/Leads: 3 Leads
RPM/Voltage/Frequency: 60 RPM, 120V ac, 50Hz
Rotor Type: Laminated
Shaft Configuration/Modification: Single/Straight key
