SCE955NN-501-01 Pacific Scientific
Wake Industrial LLC is not an authorized distributor of this product.
- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
3 Minutes
34 Seconds
The Pacific Scientific SCE955NN-501-01 is a servo drive in the SCE900 Servo Drives series. It features a continuous current of 15.9 Amps at 25°C and a peak current of 31.8 Amps. This convection cooled unit weighs 9.5 kg and has dimensions of 370 mm in height, 160 mm in width, and 229 mm in depth.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The SCE955NN-501-01 servo drive is manufactured by Pacific Scientific and belongs to the SCE900 Servo Drives series. Designed for panel-mounted deployment, the unit regulates current and voltage supplied to a matched servomotor so closed-loop motion axes in packaging, material handling, or machine-tool equipment can follow programmed trajectories accurately. By integrating command processing and power electronics into one module, the drive reduces cabinet complexity, shortens internal wiring runs, and supports precise torque and speed control during indexing, positioning, and repeated motion cycles. This arrangement also lets the controller respond quickly to command changes and load disturbances without requiring separate external amplifier hardware.
At 25 °C, the drive can supply 15.9 A of continuous output, providing stable torque production for sustained duty cycles. For rapid acceleration or shock loads, it permits a peak of 31.8 A, giving additional short-term current capacity. Heat is removed through a convection cooling without a fan design, so enclosure operation remains quiet while ambient temperature limits must still be observed. A cabinet depth of 229 mm helps the device fit shallow electrical panels, and the 900 Series designation places it within the same product family.
Overall mass is 9.5 kg, which is important when drives are mounted on lightweight backplates or densely packed subpanels. The vertical dimension of 370 mm and the frontal width of 160 mm set the cabinet space needed for installation and wiring clearance. The drive uses the Standard build, which provides default motion blocks and diagnostic routines without custom extensions. Motion profiles are executed through a Single-Axis Programmable Positioning interface and require Command Interface 5, so the control structure stays matched to the host PLC and the intended operating mode. That combination is useful when motion functions need to be handled directly at the drive level rather than through a separate positioning card.
Frequently Asked Questions about SCE955NN-501-01:
Q: What is the continuous current rating for the SCE955NN-501-01 at 25°C?
A: The SCE955NN-501-01 servo drive can supply a continuous current of 15.9 A at 25°C.
Q: What cooling method is used by the SCE955NN-501-01 servo drive?
A: This unit is convection cooled and operates without a fan.
Q: What is the peak current output for the SCE955NN-501-01?
A: The peak current for this servo drive is 31.8 A.
Q: What type of positioning interface does the SCE955NN-501-01 use?
A: The SCE955NN-501-01 features a single-axis programmable positioning interface.
Q: What operational requirement does the SCE955NN-501-01 servo drive have?
A: This model requires a valid Command Interface 5 to operate as specified.
