Product Description:

The SCE905-001-01 servo drive is produced by Pacific Scientific and belongs to the SCE900 Servo Drives series. It is a power stage that converts controller references into controlled three-phase motor current, allowing precise torque and velocity regulation in automated assembly cells, labeling systems, and similar motion applications. By providing linear amplification and feedback monitoring, the unit keeps motor response synchronized with external commands for repeatable positioning and stable load sharing across coordinated machine axes. This operating approach supports smooth speed changes and consistent response during acceleration, dwell, and deceleration.

At a reference temperature of 25 °C, the drive can deliver a continuous output of 15.9 A, which indicates the safe long-term motor current for heat-limited duty cycles. For short bursts such as rapid indexing or load impact events, it can rise to 31.8 A peak, giving extra acceleration torque without exceeding device limits. That short-term current headroom helps the motor respond quickly during brief demand spikes while preserving stable continuous operation. Command information enters through the analog or incremental digital command input, so the same hardware works with ±10 V velocity loops or step-and-direction pulse trains. Cabinet planning is simplified by the housing dimensions, which include a width of 160 mm and a depth of 229 mm, leaving additional rail space for contactors or filters.

Vertical clearance inside the enclosure must account for the unit’s 370 mm height, which allows top-mounted connectors to be accessed without strain on field wiring. The tall format also leaves room for orderly cable bends above the housing. The unit weighs 9.5 kg, which keeps handling requirements modest during panel installation. It is a Servo Drive in the 900 Series, where related modules such as regenerators or breakout boards can be used in the same motion-control platform.
