The SCE905-001-00 is a servo drive manufactured by Pacific Scientific. As part of the SCE900 Servo Drives series, it features a 3/2 way, normally closed valve type and operates at 24 VDC. The device is equipped with a DIN 43650 Form A electrical connection. Its body is made from aluminum and has an IP65 enclosure rating.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The SCE905-001-00 servo drive by Pacific Scientific works by controlling electric power to a motor by converting input signals into mechanical output. Pacific Scientific has established a renowned name in the industry of control systems by providing high-grade electromechanical designs.
This SCE905-001-00 servo drive has a large range of AC line frequency of 47 to 63 Hz using 90 to 264-volt single phase supply voltage as input. It lacks an option card and also does not have a communication or setup interface which is better suited to simpler applications of the analog or incremental digital command signal. With convection cooling at 25 degrees Celsius, it can run at the continuous rating of 15.9 amperes and a maximum of 31.8 amperes. The same peak current is realized by cooling with a forced air of 50 degrees Celsius. The internal switching frequency is rated at the low value of 20 kHz to provide minimal output current ripple to operate a smoother motor control in industrial automation. It feeds motors up to 1H maximum line-to-line inductance. The capacitance of the internal bus is able to capture an amount of energy up to 80 joules on a 650 V nominal bus which is a common 480 VAC system.
The SCE905-001-00 servo drive’s external regenerative brake is assisted with a duty cycle limit of up to 10 percent which is handy in regular acceleration braking cycles. The range of voltage handled is 180 to 528 volts by covering wider possibilities of installations. It serves to stabilize the systems with a bandwidth capability of more than 400 Hz. The environmentally safe humidity range is between 10 and 90 percent non-condensing humidity and permits up to 1500 meters altitude above sea level.
Frequently Asked Questions about SCE905-001-00:
Q: What is the input voltage range supported by the SCE905-001-00 servo drive?
A: The SCE905-001-00 supports a broad single-phase AC voltage range from 90 to 264 VAC, allowing installation flexibility across various regions.
Q: What is the maximum output peak current of the SCE905-001-00 under cooling conditions?
A: The drive with both convection and forced air cooling, delivers a consistent 31.8 A peak output current.
Q: Does the SCE905-001-00 include a communication or setup interface?
A: No, the SCE905-001-00 does not come with any installed communication or setup interface, making it ideal for direct analog or incremental digital command use.
Q: How does the SCE905-001-00 manage energy during regenerative braking?
A: The drive supports external regeneration with a 10% duty cycle and can absorb up to 80 joules from a 650 V nominal bus.
Q: What is the continuous output current of the SCE905-001-00 at 25°C?
A: At 25 degrees Celsius with convection cooling, the SCE905-001-00 provides a continuous current of 15.9 A.
