The Pacific Scientific SCE903AN-002-01 is a servo drive in the SCE900 Servo Drives series and has a continuous current rating of 5.3 A at 25°C with a peak current of 10.6 A. It is convection cooled, has a weight of 5.0 kg, and offers both analog and incremental digital command interfaces. The servo drive measures 85 mm wide, 229 mm deep, and 370 mm high.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The SCE903AN-002-01 servo drive is produced by Pacific Scientific within the SCE900 Servo Drives series. It works as a power amplifier for brushless servomotors, converting motion commands into regulated three-phase current that controls torque and speed. Current regulation, velocity control, and fault monitoring are combined in one package, so the unit supports deterministic axis control in packaging systems, material-handling equipment, and general factory automation. That arrangement lets one drive manage motor operation and protective supervision without requiring separate external monitoring modules.
At 25 °C, the drive can deliver a continuous output of 5.3 A rms, which is suitable for mid-frame rotary motors used in pick-and-place heads. For rapid index moves, it can supply a peak current of 10.6 A for several seconds, allowing the motor to overcome static friction during acceleration. Thermal management relies on a convection-cooled chassis with no fan, so heat leaves the aluminum housing through natural airflow without filters or moving parts. Command information reaches the drive through a selectable analog or incremental digital command interface, allowing it to follow ±10 V speed references or step-direction signals from PLC motion cards. Despite its output capability, the aluminum chassis weighs only 5.0 kg, which helps limit panel loading.
The rectangular enclosure is 229 mm deep, 370 mm high, and 85 mm wide, so it fits standard 300 mm cabinet rails while leaving room for cable bend radius at the rear connectors. Its narrow profile helps it fit alongside adjacent drives in multi-axis cabinets without taking excessive horizontal panel space. Rear connector placement keeps command and power wiring grouped on one face of the unit, which supports orderly cable routing in compact control enclosures. The enclosure shape also suits stacked cabinet layouts where consistent device spacing is needed.
Frequently Asked Questions about SCE903AN-002-01:
Q: What is the continuous current rating of the SCE903AN-002-01 at 25°C?
A: The SCE903AN-002-01 can deliver a continuous current of 5.3 A at 25°C for consistent servo control.
Q: How is the SCE903AN-002-01 servo drive cooled?
A: This drive is convection cooled and does not use a fan for thermal management.
Q: What command interfaces does the SCE903AN-002-01 support?
A: The SCE903AN-002-01 supports both analog and incremental digital command interfaces for flexible integration.
Q: What is the peak current output of the SCE903AN-002-01 drive?
A: This model can achieve a peak output current of 10.6 A for short periods.
Q: Which series is the SCE903AN-002-01 drive part of?
A: The SCE903AN-002-01 belongs to Pacific Scientific's SCE900 Servo Drives series.
