SC905-001-01
- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships Today
The SC905-001-01 is a compact control board weighing 180g with a maximum current of 2.5A and 24V DC input. Manufactured by Pacific Scientific as part of the SC900 Servo Drives Series, this board features DIN rail mounting and an IP20 ingress protection rating. It includes RS485 communication and operates within -20°C to 60°C.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The SC903-024-01 is a flexible and easily installed servo drive unit designed by Pacific Scientific. This product is intended for motor units from the same manufacturer. It accurately monitors the operational status of these motors and ensures that the operation is in accordance with configuration parameters. The unit is also equipped with independent protective features that allow it to gracefully deal with various operational conditions. Some of the protective features of the product include Overtemperature monitoring and protection, In-rush current limiting, output shaft circuit protection, and undervoltage protection. There is also a seven-segment status display interface installed through which errors and the current operation status of the product can be displayed. The Input/output interface of this servo drive is 24-volts logic compatible and easy to interact with.
The SC905-001-01 controller carries several authorizations that confirm its safety and performance standard. Some of these authorizations include the CSA standard, UL listing, and the IEC vibration standard. The design of the housing of this product permits only vertical installation in a control cabinet that is able to match at least the IP54 protection category. The temperature in this unit is efficiently eliminated through the process of forced ventilation, and the air blower responsible for generating cooling air in this product is located within its housing unit.
The SC905-001-01 controller operates with a bus power of about 9.0 amperes and can supply a peak output current of 10.6 amperes. The output current ripple frequency is about 20 kilohertz, its minimum motor inductance is also estimated to be about 2 megahertz. Ready-made cables from the manufacturer are available for this product; customers are recommended to make a separate order for these cables. The maximum permissible power cable length for this product is about 50 meters.
Frequently Asked Questions about SC905-001-01:
Q: How is operation status of this product communicated?
A: The SC905-001-01 features a LED-display on its front panel that helps it to communicate errors.
Q: is the SC905-001-01 shipped with connection cables?
A: No. Connection cables required for this product have to be ordered separately by operators.
Q: What is the protection category of this product?
A: The SC905-001-01 belongs to the IP20 protection classification.
Q: Is there any warranty provided for this unit?
A: Yes. Wake industrial offers customers a 12 month warranty.
Q: How can the SC905-001-01 be identified after its delivery?
A: A type label containing information about this product is attached to it upon delivery.
