SC902AN-001-01
Wake Industrial LLC is not an authorized distributor of this product.
- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The SC902AN-001-01 solenoid valve operates with a voltage of 24V DC, an operating pressure range of 0.15 to 0.7 MPa, a response time of 12 milliseconds or less, and weighs 85 grams. Part of the SC900 Servo Drives by Pacific Scientific, it features IP65 enclosure protection and a cycle life exceeding 50 million cycles.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The SC902AN-001-01 from Pacific Scientific is a high-performance solenoid valve that works well with the SC900 servo drive system.
This valve operates at 24 V DC, and can attain response times of 12 ms or better to allow fine flow control even in time-sensitive industrial processes. This valve has a pressure rating of up to 0.15 to 0.7 MPa with a port size of 1/8-inch, making it ideal to use in smaller, more compact pneumatic systems or actuator control in a localized setting. This has a temperature operating range of 5°C to 50°C, making it capable of supporting broad, multifaceted processes. The valve is made of heavy-duty aluminum alloy, which makes it lightweight (85 grams), but a long-lasting valve, cycle life of more than 50 million cycles. It has NBR (Nitrile Rubber) seals, and provides high oil and common industrial fluids resistance at the same time as it maintains sealing integrity, resulting in a long usable life. The SC902AN-001-01 may be mounted either in a manifold or base, and this allows the engineer operational freedom in the system design.
It has an IP65 enclosure rating, which makes it dustproof and resistant to low-pressure water jets, which is necessary because the environment may be exposed to minor amounts of water or need to be sealed strongly. Electrically, this unit directly interfaces to the Pacific Scientific SC900 series with a clean interface. It has a steady output current of 3.75 A at 25 °C, and it offers bursts of up to 7.5 A when operating under heavy load, allowing its actuation without the risk of overheating or electrical saturation. The SC902AN-001-01 solenoid valve is a compact, efficient, and dependable system to control motion and fluids in a high level of automation, with the low power requirement of 1.8W.
Frequently Asked Questions about SC902AN-001-01:
Q: What voltage and current does the SC902AN-001-01 operate on?
A: The SC902AN-001-01 operates at 24 V DC, with a steady current of 3.75 A at 25°C and up to 7.5 A peak for short, high-load actuation.
Q: What are the pressure and port size specifications for the SC902AN-001-01?
A: It supports a pressure range of 0.15 to 0.7 MPa and uses a 1/8-inch port size, making it ideal for compact pneumatic systems.
Q: How fast is the response time on the SC902AN-001-01 valve?
A: The SC902AN-001-01 delivers fast response times of 12 milliseconds or better, ensuring accurate control in time-sensitive applications.
Q: What materials and sealing components are used in the SC902AN-001-01?
A: The valve housing is made from aluminum alloy for durability and light weight, and it uses NBR (Nitrile Rubber) seals for excellent resistance to oils and fluids.
Q: What kind of environmental protection does the SC902AN-001-01 offer?
A: It has an IP65 protection rating, meaning it’s dust-tight and resistant to water jets, making it suitable for harsh industrial environments.
