The Pacific Scientific SC756A-001-01 is a servocontroller from the SC750 Servo Drives series that features a programmable digital position controller and supports PacSci ServoBASIC Plus programming language. It offers resolver feedback, continuous current of 60 Amps, and a peak power output of 36000 Watts. The unit provides cooling by natural convection and built-in fans, with a maximum power dissipation of 600 Watts and weighs 40.86 kilograms.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The SC756A-001-01 is a servo controller produced by Pacific Scientific and included in the SC750 Servo Drives series. In an automation cell, it functions as a closed-loop drive amplifier and motion controller, coordinating brushless servo motors and actuators so they follow programmed positions and velocities. By combining power electronics with embedded control logic, the unit bridges PLC commands and motor windings to provide precise axis regulation in assembly lines, packaging equipment, and material-handling systems. Because motion control and power delivery are handled in one unit, the controller can manage command response, motor commutation, and corrective action within the same platform.
The drive delivers a continuous output of 60 A, allowing it to supply rated torque without thermal drift, while short-term demands are supported by a 120 A peak current reserve during acceleration and shock loading. That reserve helps the axis overcome inertia at startup and respond to abrupt load changes without immediately dropping out of regulation. At maximum output, the inverter stage can deliver 36,000 W to the motor phases, and its internal losses are limited to 600 W. Heat is removed by built-in fans and natural convection, which reduces dependence on external cabinet airflow. The enclosure weighs 40.86 kg, and the +22 arcmin option is intended for applications that require tighter positional accuracy.
Control is handled by a programmable digital position controller that uses resolver feedback, which remains reliable under vibration and electrical noise. Application code is written in PacSci ServoBASIC Plus and stored in a 24K nonvolatile memory block, so the axis can restart with its saved program after power is restored. Stored logic can manage positioning routines, sequencing, and local decision-making for standalone or coordinated axis tasks. For line isolation, the input requires a 10 to 15 kVA step-down transformer. This arrangement allows the controller to run stored motion sequences without depending on a separate host processor.
Frequently Asked Questions about SC756A-001-01:
Q: What is the continuous current rating of the SC756A-001-01 servo drive?
A: The SC756A-001-01 servo drive provides a continuous current capability of 60 A.
Q: What is the peak power output of the SC756A-001-01 drive?
A: The peak power output of this servo drive is 36,000 Watts.
Q: Which programming language is supported by the SC756A-001-01 servo drive?
A: PacSci ServoBASIC Plus is the programming language used to program this drive.
Q: What type of feedback does the SC756A-001-01 utilize?
A: Resolver feedback is used for position feedback on this model.
Q: How is the SC756A-001-01 servo drive cooled?
A: This servo drive uses natural convection and built-in fans for cooling.
