Product Description:

The SC755B-001-01 servo drive is produced by Pacific Scientific within the SC750 Servo Drives series. It functions as a programmable digital position controller that powers and commands brushless servomotors used in automated material handling, packaging, and assembly stations. By integrating motion logic, bus power regulation, and feedback processing, the unit keeps each axis on target while its cooling path and built-in fans remove heat generated during continuous duty.

Key electrical limits describe how the drive couples to the DC bus and the load. The power stage runs from a bus potential of 320 Vdc and can draw up to 29 A RMS when the connected motor operates at rated torque. Under these conditions, it supplies a continuous mechanical output of 9 kW, yet it can reach a peak of 18 kW for brief acceleration or deceleration commands. Such surges are possible because the current loop tolerates up to 60 A momentarily without saturation. Resolver feedback closes the velocity and position loops, and the internal shunt network dissipates regenerated energy so the DC link remains within safe limits. A transformer sized between 5 and 7.5 kVA is recommended to prevent supply droop when multiple axes start simultaneously.

During steady production cycles, the armature carries a continuous current of 30 A, establishing the sustainable torque level for the driven mechanism. Position accuracy is held within ±4 arcmin, which is adequate for indexing tables, feeders, or moderate-precision gantries. Motion routines reside in a non-volatile memory space of 24K and are written in PacSci ServoBASIC Plus, allowing stand-alone sequencing without a supervisory PLC. The assembled chassis weighs 18.16 kg, so cabinet shelves and rail hardware must support this mass while ensuring clearance for airflow around the heat sinks.
