SC755A-040-08 Pacific Scientific
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
The Pacific Scientific SC755A-040-08 is a servocontroller from the SC750 Servo Drives series, featuring a programmable digital position controller and resolver feedback. It supports continuous currents up to 30 Amps and a peak current of 60 Amps, with peak power output reaching 18000 Watts. The unit uses both natural convection and built-in fans for cooling and has a maximum power dissipation of 300 Watts.
Internal Product Review
The SC755A-040-08 is a Pacific Scientific servocontroller with a programmable digital position controller and resolver feedback. Natural convection with built-in fans supports stable thermal management, and 60 A peak current gives this drive strong dynamic response. A 30 A continuous current rating makes the unit an excellent choice for precise, high-demand servo applications.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The SC755A-040-08 servo controller is built by Pacific Scientific for the SC750 Servo Drives series. The unit governs brushless servo axes in assembly machines, packaging lines, and similar automated equipment. As a digital position loop controller, it synthesizes command profiles, generates motor currents, and monitors process variables so each axis reaches its target without overshoot. By combining power electronics, signal conversion, and real-time control in one housing, it simplifies panel wiring and reduces the overall controller footprint. It is suited for machines that need coordinated axis response without a large control cabinet.
Electrical ratings set the drive's motion limits during continuous and short-duration operation. The drive can supply a continuous phase current of 30 A, which sustains rated torque during steady loads. For fast indexing or load impact events, it tolerates a peak current of 60 A, and this transient level is paired with a corresponding peak power output of 18000 watts. Even under those bursts, internal losses are limited to 300 watts, which helps the unit maintain thermal balance inside the enclosure. Cooling is achieved through natural convection and built-in fans, and position feedback is provided through resolver feedback so the rotor angle is decoded during each control cycle. All trajectory calculations and fault handling are executed by its programmable digital position controller, removing the need for a separate PLC axis card.
To integrate the drive on a low-voltage supply, a mains isolation transformer rated between 5 to 7.5 kVA is recommended because it provides galvanic separation and supports the expected input demand. The enclosure weight of 18.16 kg should be considered when planning a vertical panel layout, especially where mounting space is limited. Clearance around the fan inlets is necessary so airflow is not restricted during operation. An available +22 arcmin option supports applications that require tighter backlash compensation and finer positioning accuracy.
