The Pacific Scientific SC452-817-05 is part of the SC450 Brushless Servo Controllers series and serves as a programmable digital position controller with resolver feedback. It provides continuous currents of 4.2 A at 115 VAC and 3.5 A at 230 VAC, with a peak output power of 2000 W at 230 VAC. This servo controller weighs approximately 2.7 kg and can operate in temperatures from 0 to 50°C.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The SC452-817-05 servo controller is built by Pacific Scientific as part of the SC450 Brushless Servo Controllers series. Classified as a programmable digital position controller, it drives brushless servomotors and supervises motion sequences within automated machinery. By combining a motor power stage, resolver interface, and motion commands in one enclosure, the unit delivers closed-loop positioning without requiring an external PLC for basic motion control.
At 115 VAC, the power stage supplies a continuous current of 4.2 A; the rating changes to 3.5 A when the unit is connected to 230 VAC. For rapid accelerations, the drive can furnish a peak current of 7.0 A, and when operated from 230 VAC, that surge corresponds to a peak output power of 2000 W. These electrical limits suit compatible motor frame sizes without causing thermal overstress. The controller itself weighs only 2.7 kg, which simplifies panel mounting and reduces added load in moving installations. Internal monitoring tracks these operating values and shuts down the output if a limit is exceeded, while an ambient range of 0 to 50 °C supports full-duty operation in typical control cabinets. Storage is permitted from -55 to 70 °C without harming insulation while the machine is out of service.
Motion commands are executed with a basic resolution of 4096 steps per rev, giving a theoretical positioning span from 0 up to 100,000,000 steps for extended linear axes. Feedback is obtained through a resolver so the loop can hold a target to within 15 arcmin, even under vibration. A fixed switching ripple at 20 kHz keeps motor acoustics above the audible band and helps reduce torque ripple. Users develop sequences in the PacSci ServoBASIC environment and download code that uses the built-in position registers, timers, and diagnostic flags to coordinate precise pick-and-place moves without an external motion card.
Frequently Asked Questions about SC452-817-05:
Q: What is the position control range of the SC452-817-05?
A: The SC452-817-05 supports a position control range between 0 to +100,000,000 steps.
Q: What is the specified position control accuracy of the SC452-817-05?
A: Position control accuracy for this controller is rated at 15 arcminutes.
Q: What type of feedback is used with the SC452-817-05 controller?
A: The SC452-817-05 brushless servo controller utilizes resolver feedback.
Q: What is the peak output power of the SC452-817-05 at 230 VAC?
A: It delivers a peak output power of 2000 W when operating at 230 VAC.
Q: What type of configuration does the SC452-817-05 servo controller offer?
A: The SC452-817-05 features programmable digital position control and is configured as a digital position controller.
