Product Description:

The SC452-051-06 belongs to the SC450 Brushless Servo Controllers series developed by Pacific Scientific. It is a programmable digital position controller intended for closed-loop motion tasks in automated machinery. By comparing real-time resolver feedback to programmed setpoints, the unit drives a brushless servomotor so that shafts reach and hold commanded angles, speeds, or linear positions within tight tolerances.

On a 115 VAC supply, the controller can deliver a continuous phase current of 4.2 A, while a 230 VAC line permits a sustained output of 3.5 A. Short transients such as rapid accelerations are supported by a peak capability of 7.0 A, allowing the drive to overcome inertia without saturation. When operated from 230 VAC, the converter stage can source up to 2000 W to the motor, matching mid-frame servomotors used in packaging tables and small gantries. Power devices are modulated at an output ripple frequency of 20 kHz, placing the switching noise above the audible range and improving current resolution. With resolver feedback, the motion loop closes on a mechanical position increment of 4096 steps per rev, providing fine command granularity for indexing and registration tasks.

For absolute positioning, the internal counter spans a range of 0 to 100,000,000 steps, making the controller suitable for extended travel axes without wraparound. Static accuracy is maintained within 15 arcmin, so fixtures return to taught coordinates after repeated cycles. The specified operating window of 0 to 50 °C covers most cabinet environments, while an approximate weight of 2.7 kg supports DIN-rail or panel mounting without heavy supports. Storage temperatures down to −55 °C protect the electronics during shipment or storage, and resolver interfacing avoids the need for fragile optical encoders in high-vibration assemblies.
