R43HEAA-R2-NS-VS-00
Wake Industrial LLC is not an authorized distributor of this product.
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The R43HEAA-R2-NS-VS-00 is a rotary actuator delivering an output torque of 43 Nm and adjustable pneumatic cushioning. Manufactured by Pacific Scientific, this actuator is part of the R Servomotors series and features a body made of anodized aluminum. It operates within a pressure range of 2–8 bar.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
Pacific Scientific manufactures the R43HEAA-R2-NS-VS-00 Servo motor. The servo motor satisfies IP65 protection criteria and has EN60034-1 and CE certifications. The servo motor is designed for precision-controlled motion and can handle high-duty applications. The servo motor is designed for use in industrial automation systems that require precise torque and speed control.
The R43HEAA-R2-NS-VS-00 servo motor produces a continuous stall torque of 3.7 Nm, which is equivalent to 33.0 lb-in. The motor's rated speed is 3000 RPM, resulting in a power output of 1.1 kW. The servo motor has a continuous current rating of 6.9 amps and a winding resistance of 2.50 ohms. The back EMF constant is specified as 0.61 V/rad/sec, which equals 64.0 V/KRPM. The DC bus voltage is rated at 320 VDC. The servo motor has a maximum voltage rating of 600 VDC. The ambient operating temperature is 25°C, and the insulation is classified as Class F. The E61960 and E103510 are the UL certifications that the motor is designed to meet their requirements. These specifications specify the operating boundaries and ensure interoperability with control systems used in various automation configurations.
The R43HEAA-R2-NS-VS-00 servo motor weighs 6.8 kg and offers a strong base for mounting in automation components. The duty type is designated as Inverter Duty - VTVS, which corresponds to systems that use variable speed drives. The standards are designed for use in technical applications where precise torque and speed outputs are required. The servo motor is appropriate for use in industrial automation. The R43HEAA servo motor is compatible with systems that require synchronized motor control with consistent performance standards. The servo motor specifications are in line with operational consistency and compliance standards.
Frequently Asked Questions about R43HEAA-R2-NS-VS-00:
Q: Does R43HEAA-R2-NS-VS-00 support variable speed drives?
A: Yes, it is rated for Inverter Duty – VTVS that allows operation under varying speeds with thermal and electrical stability.
Q: How does the 64.0 V/KRPM Ke help R43HEAA-R2-NS-VS-00?
A: The high back EMF constant ensures accurate voltage feedback that enables precise motor control in position and speed-sensitive applications.
Q: Why is winding resistance 2.50 Ohms in R43HEAA-R2-NS-VS-00?
A: A 2.50-ohm winding resistance balances heat generation and current handling that ensures thermal safety without compromising torque output.
Q: Do the certifications in R43HEAA-R2-NS-VS-00 ensure compliance?
A: Yes, UL certifications E61960 and E103510, along with CE, ensure it meets safety and manufacturing standards for regulated environments.
Q: How does a 6.8 kg mass affect R43HEAA-R2-NS-VS-00 use?
A: The 6.8 kg motor mass provides mounting stability and reduces vibration during high-speed operation, that enhances mechanical balance.
