The Pacific Scientific N32HRFK-LNS-NS-05 is a stepper motor from the POWERPAC N Stepper Motors series and features a NEMA 34 frame with a 3.38 inch square shape. It has a holding torque of 8.6 Nm, offers 200 full steps per revolution with a step angle of 1.8°, and features a heavy duty NEMA mounting type. The motor uses a regular leadwire connection, features an 8-lead configuration, and has a single shaft design.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
Pacific Scientific manufactures the N32HRFK-LNS-NS-05 in its POWERPAC N Stepper Motors series. The motor is intended for indexing tables, automated conveyors, and other motion axes where controlled incremental rotation positions a load without closed-loop feedback. In these systems, the drive electronics issue pulse trains, and the motor converts each pulse into discrete shaft movement that advances tooling or workpieces in a predictable manner. This open-loop operating method suits applications where repeatable step execution is sufficient and direct position feedback is not required.
The housing has a 3.38 in. square frame and follows the NEMA 34 bolt pattern, so it can fit many legacy mounting plates without modification. Internally, the rotor is laminated and uses a two-stack arrangement with a standard winding to produce 200 full steps per revolution. When phase current is held, the magnetic circuit develops 8.6 Nm of holding torque to resist back-drive during dwell periods. Electrical insulation measures 100 megohms, supporting reliable operation in humid plant areas. The motor uses the standard construction style of the series and connects through regular lead wires, while heavy-duty NEMA mounting shoulders transfer belt or gear loads directly into the machine frame. Since no encoder is fitted, position is determined by pulse count, and the ±3% step accuracy suits many packaging or material-handling duties.
The insulation system also withstands test potentials up to 340 Vdc, so common DC bus voltages do not compromise dielectric strength. An 8 lead exit allows either series or parallel wiring to suit torque or speed requirements. Overall length is 133 mm, which helps preserve installation depth while still providing a rigid, single-ended shaft for couplings or pinions. Each command pulse advances the shaft by the basic 1.8° step angle, giving predictable incremental motion during repetitive indexing tasks. The laminated rotor and regular lead-wire connection support steady open-loop operation in conveyors, indexers, and similar machinery.
Frequently Asked Questions about N32HRFK-LNS-NS-05:
Q: What type of connection style is used on the N32HRFK-LNS-NS-05 stepper motor?
A: The N32HRFK-LNS-NS-05 uses a Regular/leadwire connection style for electrical interfacing.
Q: What is the holding torque of the N32HRFK-LNS-NS-05 stepper motor?
A: This model features a holding torque of 8.6 Nm, supporting demanding motion control tasks.
Q: What are the frame dimensions and type of the N32HRFK-LNS-NS-05?
A: The stepper motor has a frame size of 3.38 inches square with NEMA 34 standards.
Q: How many leads does the N32HRFK-LNS-NS-05 stepper motor have?
A: It is configured with an 8 lead leadwire, allowing for flexible wiring options.
Q: What is the step angle and number of full steps per revolution of the N32HRFK-LNS-NS-05?
A: The step angle is 1.8°, resulting in 200 full steps per revolution for precise positioning.
