The Pacific Scientific P22NSHS-LNN-NS-02 is part of the POWERMAX II P Motors series and features a NEMA 23 frame size with a standard construction type. This motor has a two-phase design, offers a step angle of 1.8 degrees, and provides 200 steps per revolution with a step accuracy of plus or minus 1.5 percent. It has an insulation class of B rated at 130°C and includes a single 6.35 mm smooth shaft configuration.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The P22NSHS-LNN-NS-02 is a two-phase hybrid stepper motor produced by Pacific Scientific for the POWERMAX II P Motors series. In automated pick-and-place stations, small conveyors, and indexing tables, it converts pulse commands into incremental shaft movement for open-loop positioning. This operating method provides repeatable step-by-step motion without requiring separate feedback hardware. Because it is a hybrid stepper design, the motor combines fine angular resolution with straightforward drive control in general automation equipment. It is intended for applications that need controlled positioning rather than continuous speed regulation from a servo loop. A smooth single shaft extends from the front face for direct coupling to gears or pulleys in compact machine layouts.
The rotor uses standard laminations and is built in a NEMA 23 frame, which fits common mounting patterns for compact motion systems. Its two-stack magnetic circuit produces 200 full steps per revolution, so each step equals 1.8 degrees and step accuracy remains within ±1.5%. Electrical connection is provided through a 4-lead parallel arrangement that supports full-step and microstep drive modes. Insulation resistance is 100 megohms under ambient test conditions, and dielectric strength is rated to 340 Vdc. This format is common in stepper applications that need predictable indexing and simple wiring between the motor and the drive. The motor is supplied without encoder feedback, which keeps the wiring straightforward.
The thermal system is rated at Class B, 130 °C. Housing temperature is limited to 95 °C to reduce heat transfer to nearby parts during continuous operation. The permitted ambient range is -20 °C to +40 °C, and the enclosure carries an IP23 rating for protection against finger contact and light sprays when the motor is installed inside machinery. The output shaft has a diameter of 6.35 mm and a smooth profile, which matches common couplings and pulleys. A standard flange pattern allows mounting to common machine interfaces used for this motor class.
Frequently Asked Questions about P22NSHS-LNN-NS-02:
Q: What is the step angle of the P22NSHS-LNN-NS-02 motor?
A: The P22NSHS-LNN-NS-02 motor has a step angle of 1.8 degrees, resulting in precise motion control for applications requiring accuracy.
Q: What frame size does the P22NSHS-LNN-NS-02 use?
A: This motor is built with a NEMA 23 frame size, making it compatible with standard NEMA 23 mounting configurations.
Q: What type and size of shaft is provided on the P22NSHS-LNN-NS-02?
A: The P22NSHS-LNN-NS-02 features a smooth, single shaft with a diameter of 6.35 mm.
Q: What are the insulation class and voltage rating of the P22NSHS-LNN-NS-02 motor?
A: The insulation for this model is rated as Class B (130°C) and withstands up to 340 Vdc.
Q: Does the P22NSHS-LNN-NS-02 motor include any feedback or encoder options?
A: This stepper motor does not include an encoder or other feedback options.
